R-222T(W)
5
NO. PARTS CODE DESCRIPTION Q'TY
PRICE RANK
[2] DOOR AND CONTROL PANEL PARTS
3-1 FPNLCB885WRKZ Control panel frame with key unit BA
3-1-1 PSHEPB158WREZ Graphic sheet AU
3-1-2 QSW-KA059DRZZ Membrane switch AQ
3-2 JBTN-B308WRFZ Open button AG
3-3 MSPRCA050WRE0 Open button spring AB
3-4 DPWBFC523WRUZ Control unit BH
3-5 QCNC-A023WRZZ Rubber connector AE
3-6 RLCDSA106DRZZ Liquid crystal display AQ
3-7 XEPS730P08XS0 Screw; 3mm x 8mm AA
3-8 PCUSUA633WREZ Cushion AE
DOOR PARTS
*
5-1 FDORFA397WRTZ Door panel assembly BB
*
5-2 GWAKPA984WRRZ Door frame AW
5-3 HPNL-A764WREZ Door screen AP
*
5-4 LSTPPA205WRFZ Latch head AF
5-5 MSPRTA187WRE0 Spring AC
5-6 PSHEPA782WREZ Sealer film AG
*
5-7 GCOVHA424WRFZ Choke cover AK
5-8 PCUSUA278WRP0 Cushion AB
MISCELLANEOUS
6-4 TINSEB282WRRZ Instruction book AP
6-5 FW-VZC044WREZ Main wire harness AQ
CONTROL PANEL PARTS
