Sharp R-326FS User Manual

37
R-326FS
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
∆
∆
∆
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-20 PCUSUA191WRP0 Cushion 1 AC
4-21 PCUSUA190WRP0 Cushion 1 AC
4-22 LANGTA360WRP0 Sensor mounting angle 1 AU
4-23 PCUSGA562WREZ Cushion 1 AC
4-24 PCUSUA192WRP0 Cushion 1 AD
DOOR PARTS
5- 1 FDORFA332WRT0 Door panel 1 BB
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 FWAKPA372WRKZ Door frame assembly 1 BH
5- 3-1 GWAKPA869WRFZ Door frame 1 AX
5- 3-2 HDECQA230WRRZ Door decoration U 1 AU
5- 3-3 HDECQA231WRPZ Door decoration L 1 AU
5- 4 HPNL-A783WRRZ Door screen 1 AT
5- 5 LSTPPA188WRF0 Latch head 1 AG
5- 6 MSPRTA187WRE0 Latch spring 1 AC
5- 7 GCOVHA405WRF0 Choke cover 1 AH
5- 8 XCPSD40P08000 Screw : 3mm x 6mm 2 AA
5- 9 PCUSGA587WREZ Cushion 1 AE
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A051WRE0 Turntable tray 1 AR
6- 3 FW-VZB970WREZ Main wire harness 1 AU
6- 4 TINSEA969WRRZ Instruction book 1 AM
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA265WRRZ DHHS caution label 1 AC
6- 7 TCAUAA254WRR0 Momitor caution 1 AC
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 6 AA
7- 2 XHPSD30P06000 Screw : 3mm x 6mm 3 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 5 AA
7- 4 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 6 XOTSD40P08000 Screw : 4mm x 8mm 17 AA
7- 7 XOTSE40P08000 Screw : 4mm x 8mm 1 AA
7- 8 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
7- 9 LX-CZ0052WRE0 Special screw 2 AA
7-10 XHPSD40P08000 Screw : 4mm x 8mm 4 AA
