36
R-326FS
*
*
*
*
∆
*
∆
*
*
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA147WRZZ Secondary interlock switch/door sensing switch 2 AG
1- 1 QSW-MA137WRE0
Secondary interlock switch/door sensing switch (Interchangeable)
2AH
1- 2 QFSHDA009WRE0 Fuse holder 1 AG
1- 3 FFS-BA023WRK0
Monitor fuse 20A and monitor switch(AM51620C53Y1) assembly
1AS
1- 4 RTHM-A127WRZZ Thermal cut-out 125 deg.C (Oven) 1 AK
1- 5 FACCDA089WREZ Power supply cord 1 AS
1- 5 FACCDA082WRE0 Power supply cord (Interchangeable) 1 AV
1- 5 FACCDA086WREZ Power supply cord (Interchangeable) 1 AN
1- 6 FH-DZA092WRK0 High voltage rectifier assembly 1 AK
1- 6 FH-DZA088WRK0 High voltage rectifier assembly (Interchangeable) 1 AP
1- 7 RC-QZA211WRE0 High voltage capacitor 1 AV
1- 7 RC-QZA286WRZZ High voltage capacitor (Interchangeable) 1 AV
1- 8 RV-MZA288WRE0 Magnetron 1 BK
1- 8 RV-MZA308WRZZ Magnetron (Interchangeable) 1 BL
1- 9 RMOTEA383WRE0 Fan motor 1 AV
1- 9 RMOTEA408WRZZ Fan motor (Interchangeable) for production use 1 --
1-10 RTRN-A670WRZZ Power transformer 1 BP
1-11 RLMPTA082WRZZ Oven lamp 1 AL
1-12 RMOTDA211WRE0 Turntable motor 1 AS
1-12 RMOTDA186WRE0 Turntable motor (Interchangeable) 1 AW
1-12 RMOTDA161WRE0 Turntable motor (Interchangeable) 1 AS
1-12 RMOTDA229WRE0 Turntable motor (Interchangeable) 1 AQ
1-13 RTHM-A120WRE0 Thermal cut-out 145 deg.C (MG.) 1 AH
1-13 RTHM-A080WRE0 Thermal cut-out 145 deg.C(MG.) (Interchangeable) 1 AP
1-14 FDTCTA197WRK0 AH senser assembly 1 BC
CABINET PARTS
2- 1 GCABUA861WRPZ Outer case cabinet 1 BE
2- 2 GDAI-A343WRWZ Bottom plate 1 AX
2- 3 GLEGPA074WRE0 Foot 1 AC
CONTROL PANEL PARTS
3- 1 FPNLCB715WRKZ Control panel frame with key unit 1 BB
3- 1-1 PSHEPA899WRZZ Graphic sheet 1 AU
3- 1-2 QSW-KA033DRZZ Membrane switch 1 AQ
3- 1-3 PSHEPA879WREZ LED sheet 1 AU
3- 1-4 RLCDSA115DRZZ Liquid crystal display 1 AU
3- 1-5 GMADIA124WRRZ Display window 1 AG
3- 1-6 HDECQA234WRPZ Conrol panel decoration 1 AU
3- 2 FBTN-A145WRKZ Open button assembly 1 AS
3- 2-1 JBTN-B185WRFZ Open button 1 AK
3- 2-2 HDECQA233WRPZ Button decoration 1 AT
3- 3 MSPRCA050WRE0 Open button spring 1 AB
3- 4 DPWBFC318WRUZ Control unit 1 BK
3- 5 QCNC-A017WRZZ Rubber connector 1 AG
3- 6 XEPSD30P08XS0 Screw; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 PCUSUA235WRP0 Cushion 1 AE
4- 2 PPACGA084WRF0 TTM packing 1 AF
4- 3 PHOK-A114WRF0 Latch hook 1 AQ
4- 4 LBNDKA099WRW0 Capacitor holder 1 AC
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A790WRWZ Fan duct 1 AZ
4- 7 ************* Oven cavity (Not a replaceable part) 1--
4- 8 LANGFA194WRW0 Chassis support 1 AU
4- 9 PCUSGA560WREZ Cushion 1 AB
4-10 MLEVPA233WRF0 Switch lever 1 AG
4-11 PCUSUA212WRP0 Cushion 2 AB
4-12 NCPL-A053WRFZ Coupling 1 AE
4-13 PCUSUA511WRP0 Cushion 2 AC
4-14 PCOVPA349WRE0 Waveguide cover 1 AE
4-15 PCUSGA339WRP0 Cushion 1 AF
4-16 PCUSGA399WRE0 Cushion 1 AF
4-17 PCUSUA524WRP0 Cushion 1 AF
4-18 PCUSGA321WRP0 Cushion 1 AH
4-19 PCUSUA474WRP0 Cushion 2 AC
To Next Page
