Sharp R-340A Service Manual

R-340A
30
*
*
*
∆
*
∆
*
*
∆
∆
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA110WRE0 1st. latch switch, 2nd. interlock relay control switch 2AK
1- 2 QSW-MA111WRE0 Monitor switch 1 AK
1- 3 FPWBFA310WRK0 Noise filter 1 AT
1- 4 RTHM-A078WRE0 Thermal cut-out 125˚C. 1 AL
1- 5 QACC-A067WRE0 Power supply cord 1 AT
1- 6 FH-DZA075WRK0 High voltage rectifier assembly 1 AR
1- 7 RC-QZA215WRE0 High voltage capacitor 1 AY
1- 7 RC-QZA182WRE0 High voltage capacitor (Interchangeable) 1 AY
1- 8 RV-MZA197WRE0 Magnetron 1 BN
1- 8 RV-MZA222WRE0 Magnetron (Interchangeable) 1 BN
1- 9 RMOTEA340WRE0 Fan motor 1 AX
1-10 QSOCLA022WRE0 Oven lamp socket 1 AG
1-11 RLMPTA069WRE0 Oven lamp 1 AK
1-12 RMOTDA169WRE0 Turntable motor 1 AW
1-13 RTHM-A079WRE0 Thermal cut-out 95 deg. 1 AL
1-14 RTRN-A530WRE0 Power transformer 1 BR
1-15 QFS-CQ001YBE0 Fuse M10A 1 AE
1-16 RR-WZA022WRE0 Monitor resistor 0.8Ω 20w 1 AK
1-17 QFS-IA002WRE0 High voltage fuse 0.75 A 1 AQ
CABINET PARTS
2- 1 GCABUA608WRP0 Outer case cabnet 1 BB
2- 2 GDAI-A261WRW0 Bottom plate left 1 AP
2- 3 GDAI-A286WRW0 Bottom plate right 1 AN
2- 4 GLEGPA019WRE0 Foot 2 AD
2- 5 GLEGPA067WRF0 Foot 1 AE
CONTROL PANEL PARTS
3- 1 CPWBFA725WRK0 Power unit 1 BC
3- 1A QCNCMA394DRE0 2-pin connector(CN-A) 1 AD
3- 1B QCNCMA275DRE0 2-pin connector(CN-B) 1 AB
3- 1C QCNCMA422DRE0 9-pin connector(CN-C) 1 AF
3- 1D FW-VZA196DRE0 Lead wire harness (WH-1) 1 AD
3- 1E LHLD-A171WRF0 LED holder 1 AE
C1 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C2 VCEAB31EW108M Capacitor 1000µF 25V 1 AE
C5 VCEAB31VW106M Capacitor 10µF 35V 1 AA
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 Diode (1SS270ATA) 4 AA
LD1-5 VHPSLZ381A9-3 Light emitting diode 5 AC
Q2 VS2SA933S//-3 Transistor (2SA933) 1 AB
Q3 VSKRC243M//-3 Transistor (KRC243M) 1 AB
R3 VRD-B12HF751J Resistor 750 ohm 1/2W 1 AA
R4 VRD-B12EF270J Resistor 27 ohm 1/4W 1 AA
R5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
Jumper 6 VRD-B12EF151J Resistor 150 ohm 1/4W 1 AA
RY1 RRLY-A021DRE0 Relay (OJSH112LM-UL) 1 AH
RY2 RRLY-A094DRE0 Relay (OMIF-S-112LM) 1 AN
SP1 RALM-A014DRE0 Buzzer (PKM22EPT-THAI) 1 AG
T1 RTRNPA108DRE0 Transformer 1 AR
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
3- 2 DPWBFB693WRK0 CPU unit 1 BE
3- 3 FPNLCB309WRK0 Control panel frame with key unit 1 BE
3- 3-1 FUNTKA819WRE0 Key unit 1 BA
3- 4 PSHEPA588WRE0 LED sheet 1 AE
3- 5 JBTN-B069WRF0 Open button 1 AF
3- 6 MSPRCA050WRE0 Open button spring 1 AB
3- 7 XEPSD30P08XS0 Screw ; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 LANGQA456WRP0 Noise filter angle 1 AG
4- 2 PCUSGA312WRP0 Cushion 1 AB
4- 3 PHOK-A095WRF0 Latch hook 1 AN
4- 4 LBNDKA099WRW0 Capacitor holder 1 AD
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A652WRP0 Fan duct 1 AU
4- 7 FOVN-A375WRT0 Oven cavity 1 BH
4- 8 LANGFA175WRP0 Chassis support 1 AX
