R380L(W)
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
1-1 QSW-MA085WRE0 AF 1st. latch / 2nd. interlock relay control switch
1-1 QSW-MA147WRZZ AG 1st. latch / 2nd. interlock relay control switch (Interchangeable)
1-1 QSW-MA137WRE0 AH 1st. latch / 2nd. interlock relay control switch (Interchangeable)
1-2 QSW-MA086WRE0 AF Monitor switch
1-2 QSW-MA148WRZZ AF Monitor switch (Intercangeable)
1-2 QSW-MA138WRE0 AH Monitor switch (Intercangeable)
1-3 QACC-A142WRZZ AQ Power supply cord
1-3 QACC-A139WRZZ -- Power supply cord for production (Intercahngeable)
1-3 QACC-A156WRZZ -- Power supply cord for production (Intercahngeable)
!
1-4 FH-DZA111WRKZ AU High voltage rectifier assembly
!
1-4 FH-DZA127WRKZ -- High voltage rectifier assembly for production (Interchangeable)
!
1-5 RC-QZA273WRZZ AU High voltage capacitor
!
1-5 RC-QZA293WRZZ AV High voltage capacitor (Interchangeable)
!
1-5 RC-QZA338WRZZ -- High voltage capacitor for production (Interchangeable)
1-6 RMOTEA405WRZZ AX Fan motor
1-6 RMOTEA390WRE0 AW Fan motor (Interchangeable)
1-7 QFS-TA014WRE0 AG Temperature fuse 150deg.C (oven)
1-8 RLMPTA088WRZZ AN Oven lamp
1-8 RLMPTA083WRZZ AM Oven lamp (Interchangeable)
1-9 RMOTDA253WRZZ AV Turntable motor
1-9 RMOTDA265WRZZ AS Turntable motor (Interchangeable)
1-9 RMOTDA173WRE0 AX Turntable motor (Interchangeable)
1-9 RMOTDA230WRE0 AS Turntable motor (Interchangeable)
!
1-10 RTRN-A756WRZZ BR Power transformer
!
1-10 RTRN-A709WRZZ BM Power transformer (Interchangeable)
!
*
1-11 RV-MZA295WRE0 BF Magnetron
1-12 FPWBFA426WRKZ AU Noise filter
1-13 QFS-CA026WRZZ AH Fuse F10A
!
1-14 QFS-IA011WRZZ AQ High voltage fuse 0.80A
1-15 FDTCTA230WRKZ AX AH sensor assembly
CABINET PARTS
2-1 GCABUA883WRPZ BF Outer case cabinet [R-380L(W)]
2-1 GCABUA935WRPZ BD Outer case cabinet [R-380L(S)]
2-2 FDAI-A269WRYZ AW Bottom plate
2-3 GLEGPA074WRE0 AC Foot
OVEN PARTS
* 4-1 PHOK-A131WRFZ AL Latch hook
4-2 LBNDKA172WRPZ AM Capacitor holder
4-3 NFANJA053WRFZ AG Fan blade
* 4-4 FOVN-A536WRTZ BF Oven cavity
4-5 MLEVPA233WRF0 AG Switch lever
4-6 GCOVHA470WRFZ AG Cover
4-7 PCOVPA394WREZ AK Waveguide cover
4-8 PDUC-A833WRPZ AM Air duct
4-9 PDUC-A854WRPZ AL Fan duct
4-10 PPACGA176WREZ AC TTM packing
4-11 PCUSGA693WRPZ AF Cushion
4-12 PCUSUA278WRP0 AB Cushion
4-13 PDUC-A842WRPZ AP Sensor duct
4-14 PCUSGA614WRPZ AE Cushion
4-15 PCUSGA615WRPZ AE Cushion
4-16 MROD-A019WREZ AN Chassis support
4-17 PCUSUA212WRP0 AB Cushion
4-18 PCUSGA620WRPZ AF Cushion
4-19 PSPAJA007WRFZ AF Spacer
4-20 PCUSGA388WRP0 AK Cushion
4-21 PCUSGA707WRPZ AC Cushion
MISCELLANEOUS
6-1 FROLPA101WRKZ AR Turntable support
6-2 NTNT-A117WREZ AS Turntable
6-3 TCAUHA343WRRZ AF Micro caution
6-4 TCAUHA214WRR0 AC K caution label
6-5 TLABMB142WRRZ AK Menu label
SCREWS
7-1 XHPS740P08K00 AB Screw : 4mm x 8mm
7-2 XOTS740P12RV0 AA Screw : 4mm x 12mm
7-3 LX-CZA073WRE0 AC Special screw
7-4 LX-CZ0052WRE0 AA Special screw
7-5 XOTS740P12000 AA Screw : 4mm x 12mm
7-6 XHPS730P06000 AB Screw : 3mm x 6mm
7-7 XHPS740P08000 AB Screw : 4mm x 8mm
7-8 XHTS740P08RV0 AG Screw : 4mm x 8mm
7-9 XHTS740P08000 AC Screw : 4mm x 8mm
7-10 XOTS740P08000 AA Screw : 4mm x 8mm
7-11 XETS740P10000 AA Screw : 4mm x 10mm
