R380L(W)
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1 DPWB-A462DRKZ BR Control unit
3-2 FPNLCB933WRKZ BA Panel sub assembly [R-380L(W)]
3-2 FPNLCB936WRKZ BB Panel sub assembly [R-380L(S)]
3-2-1 PSHEPB233WREZ AP Graphic sheet [R-380L(W)]
3-2-1 PSHEPB236WREZ AP Graphic sheet [R-380L(S)]
3-2-2 QSW-KA075DRZZ AQ Membrane switch
3-3 JBTN-B384WRFZ AG Open button [R-380L(W)]
3-3 JBTN-B385WRTZ AM Open button [R-380L(S)]
3-4 MSPRCA050WRE0 AB Button spring
3-5 XEPS730P08XS0 AB Screw : 3mm x 8mm
DOOR PARTS
* 5-1 FDORFA403WRTZ BF Door panel
5-2 PSHEPA382WRE0 AH Sealer film
* 5-3 GWAKPB075WRFZ AU Door frame [R-380L(W)]
* 5-3 GWAKPB076WRTZ BA Door frame [R-380L(S)]
5-4 HPNL-A882WRRZ AU Door screen [R-380L(W)]
5-4 HPNL-A887WRRZ AU Door screen [R-380L(S)]
* 5-5 LSTPPA188WRF0 AG Latch head
5-6 MSPRTA187WRE0 AC Spring
* 5-7 GCOVHA450WRFZ AG Choke cover
MISCELLANEOUS
6-6 TINSEB134WRRZ AP Instruction book
6-7 FW-VZB888WREZ AU Switch harness
6-8 FW-VZC125WREZ AT Main wire harness
To Next Page
