Sharp R-520LK - Parts List

39
R - 5 2 0 L K
R- 5 20LW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
∆
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB013MRY0 M High voltage rectier assembly 1 AM
1- 3 RLMPTA087WRZZ M Oven lamp/socket 1 AE
1- 4 RMOTEA433WRZZ M Fan motor 1 AL
1- 5 FFS-BA016/KIT M
Monitor switch (V-16G-2C25)and fuse assembly (20A 250V AC) 1 AF
1- 6 QSW-MA085WRE0 M
Primary interlock switch and door sensing switch (V-5230Q) 2 AE
1- 7 QFS-TA014WRE0 M Cavity temperature fuse 150
O
C 1 AF
1- 8 RV-MZA293WRE0 M Magnetron 1 BC
1- 9 RMOTDA264/KIT M Turntable motor 1 AL
1-10 RTRN-B088MRE0 M Power transformer 1 BA
1-11 FACCDB003MRE0 M Power supply cord 1 AM
1-12 QFS-TA013WRE0 M Magnetron temperature fuse 1 AE
1-13 FPWBFA380WRKZ M Noise lter unit 1 AM
1-14 FDTCTA198WRK0 M AH sensor 1 AN
CABINET PARTS
2- 1 GDAI-B061MRP0 M Base plate 1 AS
2- 2 GLEGPB004MRF0 M Foot 4 AB
2- 3 GCABUB096MRP0 M Outer case cabinet (R-520LK) 1 AV
2- 3 GCABUB089MRP0 M Outer case cabinet (R-520LW) 1 AW
CONTROL PANEL PARTS
3- 1 GPNLCB090MRK0 M Control unit assy 1 BB
3- 2 HPNLFB024MRF0 M Control panel (R-520LK) 1 AS
3- 2 HPNLFB025MRF0 M Control panel (R-520Lw) 1 AS
3- 3 FUNTKB461/KIT M Key sheet assy (R-520LK) 1 AL
3- 3 FUNTKB469/KIT M Key sheet assy (R-520LW) 1 AL
3- 4 JBTN-B201MRF0 M Open button assy (R-520LK) 1 AL
3- 4 JBTN-B203MRF0 M Open button assy (R-520LW) 1 AP
3- 5 MSPRCA045WRE0 M Open button spring 1 AA
3- 6 XEPSD30P08XS0 M Screw; 3mm x 6mm 5 AB
3- 7 QCNC-A020WRZZ M Rubber connector 1
AC
3- 8 PSHEPB037WREZ M LED sheet 1
AG
3- 9 RLCDSA116DRZZ M LCD 1
AE
3-10 LANGQB060MRP0 M PWB support angle 1
AE
3-11 HPNLCB179MRF0 M Key xing mold 1
AL
OVEN PARTS
4- 1 LBNDKB007MRP0 M H.V. Capacitor band 1 AB
4- 2 LANGTB062MRP0 M Chassis support 1 AD
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B125MRF0A M Magnetron duct 1 AE
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------- M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AH
4-10 PPACGB014MRF0 M Turntable motor packing 1 AA
4-11 PCUSUB080MRP0 M Cushion 1 AC
4-12 LANGQB025MRP0 M Noise unit angle 1 AE
4-13 PDUC-B106MRP0 M Sensor duct 1 AG
DOOR PARTS
5 -1 GWAKPB226MRR0 M Door frame (R-520LK) 1 AQ
5 -1 GWAKPB228MRR0 M Door frame (R-520LW) 1 AQ
5 -2 LSTPPB021MRF0 M Latch head 1 AD
5 -3 MSPRTA046WRE0 M Latch spring 1 AB
5 -4 FDORFB075MRT0 M Door panel 1 AW
5 -5 PSHEPB016MRE0 M Sealer lm 1 AD
5- 6 GCOVHB047MRF0 M Choke cover 1 AH
5- 7 LSTPPB045MRF0 M Door stopper 1 AA
5- 8 PGLSPB118MRE0 M Door glass (R-520LK) 1 AT
5- 8 PGLSPB124MRE0 M Door glass (R-520LW) 1 AT
5- 9 LSTPPB036MRF0 M Door glass stopper 1 AC
5- 10 PCUSUB058MRP0 M Door cushion 1 AB
5- 11 XEPS730P06XS0 M Door screw 1 AA
*
