Sharp R-530EK-T User Manual

R530EWT
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
!
1-1 RC-QZA336WRZZ AS High voltage capacitor
!
1-1 RC-QZA235WRE0 AU High voltage capacitor (Interchangeable)
!
1-1 RC-QZB018MRE0 -- High voltage capacitor for production use (Interchangeable)
!
1-2 FH-DZA131WRKZ AN High voltage rectifier assembly
1-3 RLMPTA087WRZZ AL Oven lamp
1-3 RLMPTA082WRZZ AL Oven lamp (Interchangeable)
1-3 RLMPTA085WRZZ AL Oven lamp (Interchangeable)
1-4 RMOTEA433WRZZ AX Fan motor
1-4 RMOTEA346WRE0 AV Fan motor (Interchangeable)
1-5 FFS-BA033WRKZ -- Monitor fuse (20A) and monitor switch (V-5220Q)
1-5 FFS-BA037WRKZ AN " " (20A) and monitor switch (D3V-1G-2C25) (Interchangeable)
1-6 QSW-MA085WRE0 AF Secondary interlock switch and door sensing switch
1-6 QSW-MA147WRZZ AG Secondary interlock switch and door sensing switch
1-7 QFS-TA014WRE0 AG Cavity temperature fuse 150C
1-7 RTHM-A145WRZZ AK Cavity thermal cut-out 145C
!
*
1-8 RV-MZA293WRE0 BH Magnetron
!
*
1-8 RV-MZA332WRZZ -- Magnetron for production use (Interchangeable)
1-9 RMOTDA264WRZZ AT Turntable motor
1-9 RMOTDA186WRE0 AW Turntable motor (Inerchangeable)
1-9 RMOTDA252WRZZ AN Turntable motor (Inerchangeable)
!
1-10 RTRN-A764WRZZ BH Power transformer
1-11 FACCDA103WREZ AQ Power supply cord
1-11 FACCDA085WREZ AQ Power supply cord (Interchangeable)
1-11 FACCDA083WRE0 AQ Power supply cord (Interchangeable)
1-12 QFS-TA013WRE0 AG Magnetron temperature fuse 150C
1-12 RTHM-A146WRZZ AL Magnetron thermal cut-out 145C (Interchangeable)
1-13 FPWBFA437WRKZ AS Noise filter unit
1-14 FDTCTA206WRKZ AT AH sensor
CABINET PARTS
2-1 GDAI-A439WRWZ AZ Base plate
2-2 GLEGPA104WREZ AF Leg
2-3 GCABUB116WRPZ BG Outer case cabinet (R-530EK-T)
2-3 GCABUB118WRPZ BG Outer case cabinet (R-530EW-T)
2-3 GCABUB120WRPZ BH Outer case cabinet (R-530ES-T)
OVEN PARTS
4-1 LBNDKA163WRPZ AK H.V. Capacitor band
4-2 LANGTA430WRPZ AL Chassis support
* 4-3 PHOK-A130WRFZ AK Latch hook
4-4 MLEVPA244WRFZ AG Switch lever
4-5 PDUC-B033WRFZ AM Magnetron duct
4-6 NFANJA060WRFZ AH Fan blade
4-7 PDUC-A610WRF0 AR Fan duct
* 4-8 ------------- -- Oven cavity (Not a replaceable part)
4-9 PCOVPA465WREZ AG Waveguide cover
4-10 PPACGA084WRF0 AE Turntable motor packing
4-11 PCUSGA630WRPZ AD Cushion
4-12 PCUSGA731WRPZ AF Cushion
4-13 PDUC-B031WRPZ AH Sensor duct
4-14 PCUSGA729WRPZ AB Cushion
4-15 PCUSGA730WRPZ AG Cushion
4-16 PCUSUA278WRP0 AB Cushion
MISCELLANEOUS
6-2 FROLPA117WRKZ BA Turntable support
6-3 NTNT-A099WRE0 AX Turntable tray
6-4 TCAUAA292WRRZ AE Monitor caution label
6-5 TCAUAA296WRRZ AH DHHS/Screw caution label (R-530EK-T/530EW-T)
6-5 TCAUAA278WRRZ AG DHHS/Screw caution label (R-530ES-T)
6-7 TCAUAA308WRRZ AD AC cord caution
6-9 TLABMB191WRRZ AD Menu label
SCREWS, NUTS AND WASHERS
7-1 XHPS740P08000 AB Screw : 4mm x 8mm
7-2 LX-CZ0052WRE0 AA Special screw
7-3 XHTS740P12RV0 AC Screw : 4mm x 12mm
7-4 XOTS740P12000 AA Screw : 4mm x 12mm
7-5 XCBS730P06000 AA Screw : 3mm x 6mm
7-6 XHTS740P08RV0 AG Screw : 4mm x 8mm
7-7 LX-CZA070WRE0 AC Special screw (Torx tamper proof screw)
7-8 XOTS840P08000 AB Screw : 4mm x 12mm (for R-530EK-T)
7-8 XOTS740P12000 AA Screw : 4mm x 12mm (for R-530EW-T/ES-T)
7-9 XHPS740P08K00 AB Screw : 4mm x 8mm
7-10 XOTS740P10000 AB Screw : 4mm x 10mm
7-11 XETS740P10000 AA Screw : 4mm x 10mm
