13
R-530ES
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4- 7 PDUC-B088MRF0 Fan duct 1 AC
4- 8 ------------- Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 Waveguide cover 1 AV
4-10 PPACGB014MRF0 Turntable motor packing 1 AA
4-11 PDUC-B106MRP0 Sensor duct 1 AG
4-12 PCUSU0464MRE0 Cushion 1 AC
4-13 PCUSGB037MRP0 Cushion 1 AA
DOOR PARTS
5- 1 FCOV-B132MRK0 Door frame [DMO2420B] 1 AN
5- 2 LSTPPB021MRF0 Latch head 1 AE
5- 3 MSPRTA046WRE0 Latch spring 1 AB
5 -4 FDORFB049MRT0 Door panel [DMO2420B/S] 1 AX
5- 5 PSHEPB016MRE0 Sealer film 1 AD
5- 6 GCOVHB028MRF0 Choke cover 1
MISCELLANEOUS
6- 1 FW-VZB125MRE0 Stop switch harness 1 AF
6- 2 FW-VZB168MRE0 Main wire harness 1 AU
6- 3 TLABBB007MRE0 Cavity hole cover 1 AA
6- 4 FROLPB025MRK0 Turntable support 1 AN
6- 5 NTNT-A099WRE0 Turntable tray 1 AT
6- 6 TCAUAB037MRR0 Monitor caution label 1 AA
6- 7 TCAUAB033MRR0 DHHS/Screw caution label 1 AB
6- 8 TINSEB265MRR0 Operation manual 1 AD
6- 9 QW-QZB016MRE0 High voltage wire A 1 AD
6-10 TCADUB006MRR0 Recipe card 1 AC
6-11 TLAB-B040MRR0 Menu label 1 AD
6-12 TLABBB008MRE0 UL screw caution label 1 AD
SCREWS,NUTS AND WASHERS
7- 1 LX-BZA041WRE0 Special screw 5 AA
7- 2 LX-CZ0052WRE0 Special screw 3 AA
7- 3 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 4 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AB
7- 5 XOTSD40P12000 Screw : 4mm x 12mm 11 AA
7- 6 XCBSD30P08000 Screw : 3mm x 8mm 4 AA
7- 7 LX-CZA038WRE0 Special screw 2 AA
7- 8 XHTSD40P08RV0 Screw : 4mm x 8mm 3 AA
7- 9 XOTSF40P12000 Screw : 4mm x 12mm [DMO2420B/S] 2 AA
7- 9 XOTSE40P12000 Screw : 4mm x 12mm [DMO2420R] 4 AA
