R-530ES
REF. NO. PART NO. DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
*
*
*
∆
*
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 High voltage capacitor 1 AQ
1- 2 FH-DZB008MRY0 High voltage rectifier assembly 1 AM
1- 3 QSOCLB006MRE0 Oven lamp socket 1 AE
1- 4 RLMPTA068WRE0 Oven lamp 1 AE
1- 5 RMOTEA346WRE0 Fan motor 1 AR
1- 6 QFSHDB003MRE0 Fuse holder 1 AD
1- 7 FFS-BA016/KIT
Monitor switch (V-16G-2C25) and fuse assembly (20A 250V AC) 1AF
1- 8 QSW-MA085WRE0
Secondary interlock switch and door sensing switch (V-5230Q) 2AE
1- 9 QFS-TA013WRE0 Mgnetron temperature fuse 150½C 1 AE
1-10 QFS-TA014WRE0 Cavity temperature fuse 150½C 1 AF
1-11 RV-MZA293WRE0 Magnetron 1 BE
1-12 RMOTDA211WRE0 Turntable motor 1 AK
1-13 RTRN-B066MRE0 Power transformer 1 BA
1-14 FACCDB003MRE0 Power supply cord 1 AM
1-15 FDTCTA206WRKZ AH sensor 1 AW
CABINET PARTS
2- 1 GDAI-B061MRP0 Base plate 1 BC
2- 2 GLEGPB004MRF0 Foot 4AB
2- 3 GCABUB087MRP0 Outer case cabinet 1 AY
CONTROL PANEL PARTS
3- 1 DPWBFB094MRU0 Power unit 1 BL
3- 1A QCNCMA275DRE0 J 2-pin connector (CN-A) 1 AB
3- 1B QCNCMA275DRE0 J 2-pin connector (CN-B) 1 AB
3- 1C FW-VZB146MRE0 M 12P wire harness (CN-C) 1 AU
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C4-5 VCEAB31VW106M J Capacitor 10 uF 35V 2 AA
D1-4 VHD11ES1///-1 J Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 J Diode (1SS270ATA) 4 AA
Q1-2 VS2SB1238//-3 J Transistor (2SB1238) 2 AA
Q3 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J J Resistor 2.4k ohm 1/4W 1 AA
R2 VRD-B12HF681J J Resistor 680 ohm 1/2W 1 AA
R3 VRD-B12HF511J J Resistor 510 ohm 1/2W 1 AB
R4 VRD-B12EF270J J Resistor 27 ohm 1/4W 1 AA
R5 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
RY1-2 RRLY-A113DRE0 M Relay (DU24D1-1PR(M)) 2 AG
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB009MRE0 M Transformer 1 BC
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
VRS1 RH-VZB002MRE0 M Varistor (470ND-10D) (Interchangeable) 1 AE
ZD1 VHEHZ161///-1 J Zener diode (HZ16-1) 1 AA
3- 2 DPWBFC167WRKZ LSI unit 1 BC
3- 3 FPNLCB346MRK0 Control panel frame assembly 1 AV
3-3-1 FUNTKB281MRE0 Key unit 1 AL
3-3-2 JBTN-B091MRF0 Open button 1 AD
3-3-3 HDECAB049MRP0 Decoration
plate 1AF
3-3-4 MSPRTA050WRE0 Open button spring 1 AA
3- 4 LHLD-B006MRF0 LCD holder 1 AF
3- 5 PSHEPB027MRE0 LED sheet 1 AF
3- 6 XEPSD30P10XS0 Screw; 3mm x 10mm 3 AA
OVEN PARTS
4- 1 LBNDKB007MRP0 H.V. Capacitor band 1 AB
4- 2 LANGTB049MRP0 Chassis support 1 AE
4- 3 PHOK-B018MRF0 Latch hook 1 AF
4- 4 MLEVPB016MRF0 Switch lever 1 AD
4- 5 PDUC-B104MRF0 Magnetron duct 1 AG
4- 6 NFANPB006MRE0 Fan blade 1 AC
