14
R-880F(S)
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
E SWITCH TEST
CARRY OUT 3D CHECKS.
Isolate the switch to be tested and using an ohmmeter check between the terminals as described in
the following table.
Table: Terminal Connection of Switch
Plunger Operation COM to NO COM to NC
Released Open circuit Short circuit
Depressed Short circuit Open circuit
COM; Common terminal,
NO; Normally open terminal
NC; Normally close terminal
If incorrect readings are obtained, make the necessary switch adjustment or replace the switch.
CARRY OUT 4R CHECKS.
F THERMAL CUT-OUT TEST
CARRY OUT 3D CHECKS.
Disconnect the leads from the terminals of the thermal cut-out. Then using an ohmmeter, make a continuity
test across the two terminals as described in the below.
Table: Thermal Cut-out Test
Temperature of "ON" Temperature of "OFF" Indication of ohmmeter
Parts Name condition (closed circuit). condition (open circuit). (When room temperature
(˚C) (˚C) is approx. 20˚C.)
Thermal cut-out 125˚C This is not resetable type. Above 125˚C Closed circuit
Thermal cut-out 170˚C Cuts back in at 155˚C. Above 170˚C Closed circuit
If incorrect readings are obtained, replace the thermal cut-out.
An open circuit thermal cut-out (MG) indicates that the magnetron has overheated, this may be due
to resistricted ventilation, cooling fan failure or a fault condition within the magnetron or HV. circuit.
An open circuit thermal cut-out (OVEN) indicates that the food in the oven cavity may catch fire, this
may be due to over heating produced by improper setting of the cooking timer or failure of the control
panel.
CARRY OUT 4R CHECKS.
G BLOWN FUSE F10A
CARRY OUT 3D CHECKS.
If the fuse F10A is blown when the door is opened, check the 1st. latch switch, 2nd. interlock relay and
monitor switch.
If the fuse F10A is blown, there could be a short or ground in electrical parts or wire harness. Check
them and replace the defective parts or repair the wire harness.
CARRY OUT 4R CHECKS.
CAUTION: Only replace fuse F10A with the correct value replacement.
C. A normal capacitor shows continuity for a short time (kick) and then a resistance of about 10MΩ after
it has been charged.
D. A short-circuited capacitor shows continuity all the time.
E. An open capacitor constantly shows a resistance about 10 MΩ because of its internal 10MΩ
resistance.
F. When the internal wire is opened in the high voltage capacitor shows an infinite resistance.
G. The resistance across all the terminals and the chassis must be infinite when the capacitor is
normal.
If incorrect reading are obtained, the high voltage capacitor must be replaced.
CARRY OUT 4R CHECKS.
