Sharp R-880F User Manual

R-880F(S)
41
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆
*
∆
*
*
*
ELECTRIC PARTS
1- 1 QSW-MA131WRE0 1st. latch switch, 2nd. interlock relay control switch 2 AG
1- 1 QSW-MA110WRE0 1st. latch switch, 2nd. interlock relay control switch (Interchangeable) 2AH
1- 2 QSW-MA132WRE0 Monitor switch 1 AH
1- 2 QSW-MA111WRE0 Monitor switch (Interchangeable) 1 AH
1- 3 RMOTDA227WRE0 Turntable motor 1 AW
1- 3 RMOTDA228WRE0 Turntable motor (Interchangeable) 1 AU
1- 3 RMOTDA207WRE0 Turntable motor (Interchangeable) 1 AT
1- 4 FH-DZA080WRK0 High voltage rectifier assembly 1 AM
1- 5 RC-QZA215WRE0 High voltage capacitor 1 AY
1- 5 RC-QZA290WRZZ High voltage capacitor (Interchangeable) for prduction use 1--
1- 6 RMOTEA361WRE0 Fan motor 1 AW
1- 6 RMOTEA369WRE0 Fan motor (Interchangeable) for prduction use 1--
1- 7 FPWBFA355WRKZ Noise filter 1 AY
1- 8 QACCAA049WRZZ Power supply cord 1 AW
1- 8 QACCAA042WRE0 Power supply cord (Interchangeable) 1 AX
1- 8 QACCAA047WRE0 Power supply cord (Interchangeable) 1 AP
1- 9 QFS-BA007WRE0 Fuse 15A 1 AF
1-10 QFS-CA026WRZZ Fuse F10A 1 AH
1-11 QTANNA017WRW0 Short terminal 1 AD
1-12 RHET-A213WRE0 Grill heater (Top heater) 2 AU
1-13 RHET-A212WRE0 Bottom heater 1 BA
1-14 RLMPTA078WRE0 Oven lamp 1 AL
1-14 RLMPTA080WRE0 Oven lamp (Interchangeable) for prduction use 1 --
1-15 QSOCLA024WRE0 Oven lamp socket 1 AH
1-15 QSOCLA022WRE0 Oven lamp socket (Interchangeable) 1 AG
1-15 QSOCLA011WRE0 Oven lamp socket (Interchangeable) 1 AH
1-16 RTHM-A109WRE0 Thermal cut out 170˚C OFF / 155˚C ON (Oven) 1 AM
1-16 RTHM-A048WRE0
Thermal cut out 170˚C OFF / 155˚C ON (Oven)(Interchangeable) 1AH
1-17 RTHM-A078WRE0 Thermal cut-out 125˚C (MG.) 1 AK
1-17 RTHM-A098WRE0 Thermal cut-out 125˚C (MG.) (Interchangeable) 1 AK
1-17 RTHM-A116WRE0 Thermal cut-out 125˚C (MG.) (Interchangeable) 1 AK
1-18 RTRN-A573WRE0 High voltage transformer 1 BN
1-19 RV-MZA222WRE0 Magnetron 1 BN
1-19 RV-MZA294WRE0 Magnetron (Interchangeable) 1 BL
1-20 FDTCTA192WRK0 AH sensor assembly 1 AV
1-21 FH-HZA063WRE0 Thermistor 1 AP
1-22 RMOTEA373WRE0 Convection motor 1 AW
1-23 QFS-IA006WRE0 H.V. fuse 0.75A 1 AQ
1-23 QFS-IA008WRZZ H.V. fuse 0.8A (Interchangeable) for prduction use 1--
CABINET PARTS
2- 1 GCABDA097WRW0 Back plate 1 AW
2- 2 GCABUA707WRP0 Outer case cabinet 1 AZ
2- 3 GDAI-A305WRW0 Base plate 1 AX
2- 4 GLEGPA074WRE0 Leg 2 AC
CONTROL PANEL PARTS
3- 1 DPWBFB872WRK0 Power unit (New Zealand only) 1 BE
3- 1A QCNCMA234DRE0 3-pin connector (CN-A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector (CN-B) 1 AB
3- 1C FW-VZA238DRE0 9pin wire harness (WH-1, WH-2) 2 AK
3- 1D QCNCMA410DRE0 2-pin connector (CN-D) 1 AB
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31VW108M Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C4-5 VCEAB31VW106M Capacitor 10 uF 35V 2 AA
D1-4 RH-DZA006PRE0 Diode (1N4002) 4 AD
D5-12 VHD1SS270A/-1 Diode (1SS270A) 8 AA
Q1-2 VS2SB1238//-3 Transistor (2SB1238) 2 AA
Q3 VSKRC243M//-3 Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J Resistor 2.4k ohm 1/4W 1 AA
R2 VRD-B12HF681J Resistor 680 ohm 1/2W 1 AA
R3 VRD-B12HF511J Resistor 510 ohm 1/2W 1 AB
R4 VRD-B12EF270J Resistor 27 ohm 1/4W 1 AB
R5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A080DRE0 Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A081DRE0 Relay (VRB24) 1 AL
RY3-4 RRLY-A076DRE0 Relay (OMIF-S-124LM) 2 AK
RY5 RRLY-A080DRE0 Relay (OJ-SH-124LM) 1 AG
RY6 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
SP1 RALM-A014DRE0 Buzzer (PKM22EPT-THAI) 1 AG
