Sharp R-880F User Manual

42
R-880F(S)
∆
∆
∆
∆
∆
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
T1 RTRNPA105DRE0 Transformer 1 AS
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 Zener diode (HZ16-1) 1 AA
3- 2 DPWBFC291WRKZ CPU unit 1 BF
3- 3 DPNLCB745WRKZ Control panel frame with key unit 1 BB
3- 3-1 JBTN-B092WRF0 Open button 1 AF
3- 3-2 MSPRCA050WRE0 Open button spring 1 AB
3- 3-3 FUNTKB129WREZ Key unit 1 AX
3- 4 LHLD-A185WRF0 LCD holder 1 AL
3- 5 PSHEPA626WRE0 LED sheet 1 AF
3- 6 XEPSD30P08XS0 Screw; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 DOVN-A517WRY0 Oven cavity 1 BT
4- 2 PHOK-A106WRF0 Latch hook 1 AL
4- 3 FDUC-A338WRK0 Air duct assembly 1 BF
4- 4 PCUSGA389WRP0 Cushion 1 AG
4- 5 LANGQA478WRP0 Turntable motor angle 1 AP
4- 6 MSPRTA186WRE0 Plate spring 1 AE
4- 7 NCPL-A051WRE0 Turntable motor shaft 1 AN
4- 8 PSPA-A109WRE0 Spacer 1 AB
4- 9 LBNDKA136WRP0 HV capacitor holder 1 AQ
4-10 NFANJA041WRE0 Fan blade 1 AF
4-11 PDUC-A697WRF0 Fan duct 1 AM
4-12 GCOVHA388WRW0 Bottom heater cover 1 AF
4-13 GLEGPA071WRF0 Leg 1 AG
4-14 LANGFA191WRW0 Chassis support 1 AN
4-15 PCOVPA340WRW0 Sub back plate 1 AQ
4-16 LFLG-A030WREZ Bearing 1 AM
4-17 MLEVPA226WRF0 Switch lever 1 AF
4-18 MSPR-A004WRE0 Heat seal spring 2 AF
4-19 PCOV-A011WRP0 Bottom heater angle 2 AM
4-20 PCOVPA339WRE0 Waveguide cover 1 AF
4-21 PCUSGA385WRP0 Cushion 1 AH
4-22 PCUSUA190WRP0 Cushion 1 AC
4-23 PCUSUA191WRP0 Cushion 1 AC
4-24 PDUC-A691WRF0 Air intake duct 1 AG
4-25 PDUC-A692WRP0 Exhaust 1 AS
4-26 PDUC-A784WRWZ Air guide 1 AP
4-27 PGLSPA518WRE0 Light glass 1 AZ
4-28 PCUSGA399WRE0 Cushion 1 AF
4-29 PREFHA061WRW0 Reflector 1 BE
4-30 PSHEPA487WRE0 Heater film 1 AA
4-31 PSKR-A358WRP0 Air separate angle 1 AX
4-32 MSPRCA113WRE0 H-spring 2 AC
4-33 PCUSGA420WRP0 Cushion 1 AE
4-34 LANGQA489WRP0 Thermistor angle 1 AW
4-35 NFANMA047WRP0 Convection fan 1 AX
4-36 NFANMA048WRP0 Cooling fan 1 AX
4-37 PCUSUA499WRP0 Cushion 1 AC
4-38 PDUC-A707WRW0 Convection duct 1 AR
4-39 PFPF-A210WRE0 Thermal insulation 1 AM
4-40 PPIPFA030WRE0 Pipe 1 AK
4-41 PSKR-A339WRP0 Convection air angle 2 AX
4-42 PSKR-A345WRW0 Convection motor guide A 1 AU
4-43 PSKR-A346WRW0 Convection motor guide B 1 AR
4-44 PSLDHA140WRW0 Convection thermal cover 1 AQ
DOOR PARTS
5- 1 DDORFA857WRK0 Door panel assembly 1 BB
5- 2 GWAKPA872WRRZ Door frame 1 AY
5- 3 LSTPPA176WRF0 Latch head 1 AN
5- 4 LSTPPA177WRF0 Glass stopper 1 AF
5- 5 MSPRTA187WRE0 Latch spring 1 AC
5- 6 PGLSPA513WRE0 Front door glass 1 AV
5- 7 XCPSD40P08000 Screw : 4mm x 8mm 6 AA
5- 8 GCOVHA387WRF0 Choke cover 1 AS
MISCELLANEOUS
6- 1 FAMI-A099WRM0 High rack 1 AS
6- 2 FAMI-A100WRM0 Low rack 1 AS
6- 3 FSRAHA063WRYZ Turntable support 1 AK
6- 4 NTNT-A092WRH0 Turntable 1 AZ
6- 5 TLABMA584WRR0 Menu label 1 AF
6- 6 TINSEA956WRRZ Instruction book 1 AP
*
