General Information
- Controls and indicators -
Controls and indicators (continued)
! Front speaker 2
1.Bass Reflex Duct
2.Speakers
3.Speaker Terminals
4.Mounting Holes for Stand or Bracket
! Centre speaker 1
1.Bass Reflex Duct
2.Speakers
3.Mounting Holes for Bracket
4.Speaker Terminals
! Surround speaker 2
1.Bass Reflex Duct
2.Speaker
3.Speaker Terminals
4.Mounting Holes for Stand or Bracket
! Subwoofer 1
1.Bass Reflex Duct
2.Woofer
3.Speaker Terminals
1
3
4
2
1
4
3
2
1
3
2
4
1
2
3
