4
SJ-21P
SJ-D25P
1. Freezer shelf (Small) [F-partition tray]
2. Ice cube maker
3. Ice cube box [Ice storage box]
4. Freezer shelf (Large) [F tray]
5. Freezer temp. control knob
6. Refrigerator temp. control knob
7. Light [Lamp]
Replacing the lamp bulb
Replace lamp bulb with same type.
Base E12, MAX 10W
Make sure that the rated voltage and wattage of the
lamp bulb are correct when replacing (check the label
near the bulb).
8. Refrigerator shelf (Small) [R tray S]
9. Refrigerator shelf (Large) [R tray L]
10. Three position adjustable shelf [Free set shelf]
This shelf has three positions, it can be partly or fully
extended or be fully folded away simply by pushing
the shelf back then lifting it up.
Deodorizing unit (Only for SJ-D25P)
A built-in unit which requires no manual operation
because it automatically starts operating when the
refrigerator is powered on.
DESIGNATION OF VARIOUS PARTS
EXTERNAL DESCRIPTION
By Operation manual
Fig. D-1
The names in parenthesis" [ ]" are the denominations used in the REPLACEMENT PARTS LIST.
SJ-D25PSJ-21P
15. Table top [Top table]
Do not place hot objects on the table top. The table
top may melt and deform. The table can resist
temperatures up to 100˚C.
16. Freezer pocket [F door pocket]
17. Light switch
18. Magnetic door seal [Door packing]
19. Egg holder [Egg tray]
20. Free pocket [R door pocket]
21. Bottle pocket
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
16
18
19
20
21
1
2
3
4
5
6
7
8
10
9
11
12
13
14
15
16
17
16
18
20
21
19
11. Evaporating pan
12. Shelf [V tray]
13. Fruit and vegetable crisper [Vegetable case]
14. Adjustable foot [Adjustable leg]
