26
SJ-43L-A2
SJ-47L-A2
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST(SJ-47L-A2G/A2S/A2A)
SJ-47L SJ-47L SJ-47L
-A2G -A2S -A2A
ELECTRIC PARTS
1-1 RTHM-A103CBZZ F-themostat 1 1 1 AV
1-2 RSTT-A134CBE0 Starting relay 1 1 1 AS
1-3 QSWTDA047CBZZ Defrost timer 1 1 1 AZ
1-4 PDMP-A050CBEZ Damper thermo 1 1 1 AW
1-5 FTHM-A039CBKZ Defrost thermo.ass'y 1 1 1 AM
1-6 RMOTRA046CBE0 Fan motor 1 1 1 AZ
1-7 QSOCAA084CBEZ Lamp socket 1 1 1 AL
1-8 RLMP-A029CBEZ Lamp15w 1 1 1 AH
1-9 QACC-A142CBZZ Source cord 1 1 1 AQ
1-10 QSW-PA090CBZA Door switch 1 1 1 AS
1-11 RHOG-A161CBZZ Protector 1 1 1 AX
1-17 FFS-TA061CBKZ Fuse ass'y 1 1 1 AM
1-20 FW-VZA146CBEZ Lead ev-cover ass'y 1 1 1 AL
1-21 FHETBA161CBEZ Def.heater ass'y 1 1 1 AY
1-22 FCNW-A688CBKZ Relay cord s ass'y 1 1 1 AR
1-23 QCNW-A969CBZZ Reray wire rc 1 1 1 AD
1-32 RC-EZA195CBZZ Running capacitor 1 1 1 BB
1-33 QCNW-A886CBE0 Olr cord 1 1 1 AE
MECHANICAL PARTS
2-2 JKNB-A036CBFC F-temp. control knob 1 1 1 AC
2-4 LHLD-A489CBFA E.v. holder 2 2 2 AD
2-7 FLEGPA083CBKZ Leg holder l ass'y 1 1 1 AF
2-7-1 FAJS-A015CBKZ Adjustable leg ass'y 2 2 2 AE
2-7-2 LHLD-A533CBPZ Leg holder l 1 1 1 AL
2-8 FLEGPA084CBKZ Leg holder r ass'y 1 1 1 AF
2-8-2 LHLD-A534CBPZ Leg holder r 1 1 1 AP
2-13 DHNG-A417CBMZ Upper hinge ass'y 1 1 1 AE
2-14 DHNG-A419CBMZ Bottom hinge r ass'y 1 1 1 AD
2-15 DHNG-A418CBMZ Center hinge r ass'y 1 1 1 AE
2-16 GCOV-A210CBFZ E.v cover 1 1 1 AR
2-17 LCRA-A010CBE0 Fan clamp 1 1 1 AD
2-19 LHLD-A389CBF0 Motor cushion 2 2 2 AF
2-20 NFANPA011CBF0 Propeller fan 100 1 1 1 AD
2-21 PSEL-C067CBEZ E.v cover sealer a 1 1 1 AA
2-22 PSEL-C068CBEZ E.v cover sealer b 1 1 1 AA
2-23 PSEL-C066CBEZ E.v cover sealer c 1 1 1 AC
2-24 PCOVPA308CBFA Terminal cover 1 1 1 AE
2-26 PCOV-A277CBFA R lamp cover 1 1 1 AE
2-27 GCOVPA142CBRA R-c box cover 1 1 1 AQ
2-28 HGRL-A206CBRA Fan louver 1 1 1 AS
2-29 GCOV-A209CBFA Upper hinge cover 1 - - AC
2-29 GCOV-A209CBFB Upper hinge cover - 1 - AC
2-29 GCOV-A209CBFE Upper hinge cover - - 1 AD
2-31 JKNB-A033CBFC R-temp.control knob 1 1 1 AC
2-32 JKNB-A063CBFA V-tray control knob 1 1 1 AC
2-36 PCAP-A006CBFX Screw cover 2 - - AB
2-36 PCAP-A006CBFY Screw cover - - 2 AB
2-36 PCAP-A077CBFA Screw cover - 2 - AA
2-38 PGID-A161CBFZ R-air guider 1 1 1 AG
2-39 PGID-A162CBFZ R-air guider s 1 1 1 AC
2-41 PSEL-B848CBEZ A-sealer thermo.cap 1 1 1 AC
2-44 HGRL-A203CBRA F deodo.louver 1 1 1 AF
2-45 HGRL-A204CBFA R deodo.louver 1 1 1 AE
2-46 PFIL-A047CBEZ Deodorizer 2 2 2 AC
2-49 LSTPPA108CBFA Chilled stopper 2 2 2 AC
2-50 LSTPPA118CBFA Case stopper v 2 2 2 AC
2-55 HGRL-A205CBFA Multi louver l 1 1 1 AM
2-56 PFPFPB334CBFZ R-louver insu.l 1 1 1 AE
2-57 PSEL-C085CBEZ A-sealer r-louver 2 2 2 AC
2-63 LHLD-A484CBFA Fan motor holder b 1 1 1 AH
2-64 LHLD-A485CBFA Fan motor holder a 1 1 1 AH
2-65 PSEL-B209CBE0 U-sealer handle 2 2 2 AB
2-66 PSHEMA225CBPZ Heater cover 1 1 1 AC
2-67 LPLTMA633CBPZ Drain support al 1 1 1 AF
2-68 PSEL-A415CBE0 E.v cover sealer c 1 1 1 AC
2-69 PSEL-C069CBEZ E.v cover sealer d 1 1 1 AA
2-70 PSEL-C135CBEZ E.v cover sealer e 1 1 1 AC
2-71 PSEL-A552CBE0 Dial sealer 1 1 1 AC
2-72 PSEL-C078CBEZ A-sealer ag1 2 2 2 AC
2-73 PSEL-C079CBEZ A-sealer ag2 1 1 1 AB
2-77 LHLD-A391CBE0 Sl-5n clip 1 1 1 AD
2-78 LPLTMA399CBP0 Dryer support 1 1 1 AD
