From Suction pipe
to SP connector
From Compressor
to Charge pipe
From Dryer
to Capillary tub
e
From Discharge p connector
to Eva-pan pipe ass'y
From SP connector
to Compressor
From Compressor
to Discharge p connector
From Eva-pan pipe ass'y
to Back condenser In
F
rom Back condenser out
t
o Hot pipe
From Hot pipe
to Dryer
Figure C-3. Location (SJ-44L-WH1,SJ-48L-WH1)
Figure C-2. Location
Compressor
Suction pipe
Charge pipe
Charge pipe
Capillary tube
Dryer
Hot pip
e
S.P. connector
Eva-pan pipe
Back condenser
E
vaporator
From Suction pipe
to SP connector
From Compressor
to Charge pipe
From Dryer
to Capillary tub
e
From Discharge p connector
to Eva-pan pipe ass’y
From SP connector
to Compressor
From Compressor
to Discharge p connector
From Eva-pan pipe ass’y
to Back condenser In
F
rom Back condenser out
t
o Hot pipe
From Hot pipe
to Dryer
Figure C-4. Location (SJ-44L-WH2,SJ-48L-WH2)
