SJ-68L-T2
LIST OF ELECTRICAL PARTS
ITEMS TYPE NAME RATING SPECIFICATIONS
Thermostat MM1-8123 125V 6A (At normal notch)
250V 3A ON/OFF : -19/-24˚C
Defrost thermostat S101 250V 8A Open/Close : 10/1˚C
Thermo. fuse SF70E 250V 10A Working temp. : 70˚C
F-fan motor 3R00044B 220-240V 50/60Hz Working with ø100 fan
R-fan motor 3R00122A 220-240V 50/60Hz Working with ø80 fan
(R-fan fuse) 123 250V 2A Cut OFF 130˚C
Defrost heater MM6-4198 220-240V 353Ω 150W at 230V
Door switch DSD-5 250V 0.25A 4 terminals push-button type
Damper thermostat MM1-6170 — Open/Close : 3/-2˚C
Defrost timer TMDF904FD2 220-240V Integration type
50/60Hz Cycle time : 10.8/9.0 hours(50/60Hz)
Delay time : 4.3/3.6 min.(50/60Hz)
Lamp socket (F/R) — 250V 1A E-12(Hard plastic body type)
F-lamp — 240V 10W E-12
R-lamp — 240V 15W E-12
R-fan thermo.
R-fan thermo.
S101 250V 8A Open/ Close : 7/15˚C
ass'y
R-fan thermo.heater
RSS2 350V, 2W, 10kΩ 1.1W at 230V
Compressor GLY90AA 220-240V/50Hz Cooling capacity : 220kcal/h(50Hz)
Main coil : 8.8Ω
Aux. coil : 14.2Ω
(at 25˚C)
Starting relay UH3003-7 — 14.0 Ω 30%
Runnig capacitor — 430VAC 5µF
Overload relay(Protector) 4TM757NFBYY — Open/ Close : 120/61˚C
+
Common
Main coil
Aux. coil
