SJF800SPSL
6 – 1
SJF800SPSL
ServiceManual
CHAPTER 6. LIST OF ELECTORICAL PARTS
“ • “ denotes parts that cannot be replaced or parts that cannot be replaced as an individual unit.
ITEMS TYPE NAME RATING SPECIFICATIONS
R Thermistor — DC 5V R0 = 6.4 kΩ, B(0) = 3811
F Thermistor — DC 5V R0 = 6.4 kΩ, B(0) = 3811
Defrost Themistor — DC 5V R0 = 15 kΩ, B(0) = 3811
• RD Heater (F750SP) — 220-240V 8021Ω 6.6W at 230V
• RD Heater (F800SP) — 220-240V 8365Ω 6.32W at 230V
Thermo. fuse SF70E 250V 10A Working temp. : 70 °C
Defrost heater MM6-4350 220-240V 286Ω 185W at 230V
R-Fan motor D08A-12PM.05(K) DC12V 0.07A —
F-Fan motor FBA12J15VXD DC14.5V 0.28A —
C-Fan motor D09T-12CS307(EX) DC12V 0.09A —
Damper NSBC101FA1 DC12V —
Reed SW MS-332/651 DC5V Magnetic Switch
SW Magnet FM10.9X7X25.4(SR-3) — Magnet Switch
Lamp (Side) FPWB-A617CBKZ DC14.5V 150mA white LED Lamp
Lamp (Top) FPWB-A619CBKZ DC14.5V 75mA white LED Lamp
LCD operation FPWB-A615CBKZ DC14.5V Blue LCD
Ionizer indicator FPWB-A621CBKZ DC14.5V Blue LED
Compressor EGM90CLC 220-240V/50Hz Cooling capacity : 218W (50Hz)
Main coil : 18.40Ω
Aux. coil : 25.50Ω
(at 25 °C)
Starting Relay PTH8M220MD2 — 22Ω (at 25 °C)
Overload Relay (Protector) 4TM189NFBYY-53 — Open/Close : 120/ 61 °C
Running capacitor RC-EZA254CBZZ — 400V 5μF
Ionizer-K (Plasmacluster unit) CKITTA131AKKZ DC15V 4.55kV p-p (Second wave)
