SJ-P43N/43N
SJ-P47N/47N
LIST OF ELECTRICAL PARTS
ITEMS TYPE NAME RATING SPECIFICATIONS
Thermostat MM1-8149 125V 6A (At normal notch)
250V 3A ON/OFF : -20 / -25˚C
Defrost thermostat S101 250V 8A Open/Close : 8 / 1˚C
Thermo. fuse SF70E 250V 10A Working temp. : 70˚C
Fan motor 3R00171 110-120V 60Hz Working with ø100 fan
Defrost heater MM1-4266 115V 94.5 140W at 115V
Door switch DSD-5 125V 0.5A 4 terminals push-button type
Damper thermostat MM1-6173 Open/Close : 5 / 0˚C
Defrost timer TMDFX04FB2 110-127V Integration type
50/60Hz Cycle time : 12h/10h(50/60Hz)
Delay time : 4m48s/4m(50/60Hz)
Lamp socket 250V 1A E-12(Hard plastic body type)
Lamp 110V 15W E-12
Compressor FL1568PF 110V/60Hz Cooling capacity : 210W (60Hz)
Main coil : 1.99
Aux. coil : 3.27
(at 75˚C)
Starting relay P5T0SAT 5.6
Overload relay(Protector) 3.6C36C1 Open/ Close : 130/60˚C
Running Capacitor 250V 14µF—
Ionizer-K
(Plasmacluster unit)
FTRN-A014CBKZ DC12V 3.5kV p-p
(Only for SJ-P43N,P47N)
Common
Main coil
Aux. coil
