27
SJ-P43N/43N
SJ-P47N/47N
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST(SJ-P43N/43N/P47N/47N)
SJ-P43N SJ-43N SJ-P47N SJ-47N
-SL -BE -SL -BE
ELECTRIC PARTS
1- 1 RTHM-A103CBZZ F-themostat 1 1 1 1 AV
1- 2 RSTT-A176CBZZ Starting relay 1 1 1 1 AS
1- 3 QSWTDA025CBE0 Defrost timer 1 1 1 1 AW
1- 4 PDMP-A050CBEZ Damper thermo 1 1 1 1 AW
1- 5 FTHM-A039CBKZ Defrost thermo.ass’y 1 1 1 1 AM
1- 6 RMOTRA071CBZZ Fan motor 1 1 1 1 AY
1- 7 QSOCAA084CBEZ Lamp socket 1 1 1 1 AL
1- 8 RLMP-A028CBEZ Lamp15w 1 1 1 1 AG
1- 9 QACC-A160CBZZ Source cord 1 1 1 1 AP
1- 10 QSW-PA090CBZA Door switch 1 1 1 1 AS
1- 11 RHOG-A165CBZZ Protector 1 1 1 1 AZ
1- 17 FFS-TA061CBKZ Fuse ass’y 1 1 1 1 AM
1- 20 FW-VZA148CBEZ Lead ev-cover ass’y 1 1 1 1 AL
1- 21 FHETBA164CBEZ Def.heater ass’y 1 1 1 1 AX
1- 22 FCNW-A733CBKZ Relay wire ass’y 1 1 1 1 AP
1- 23 QCNW-A671CBE0 Reray wire rc 1 1 1 1 AD
1- 32 RC-EZA197CBZZ Capacitor 1 1 1 1
1- 33 QCNW-A886CBE0 Olr cord 1 1 1 1 AE
1- 34 QCNW-A887CBE0 Earth wire 1 1 1 1 AG
1- 45 FTRN-A014CBKZ Ionaizer-k 1 - 1 - AZ
1- 46 QCNW-B104CBZZ Plasma harness 1 - 1 - AF
1- 50 FPWB-A347CBKZ Main pwb 1 - 1 -
1- 55 FPWB-A336CBKZ Panel pwb ass’y 1 - 1 - AT
MECHANICAL PARTS
2- 2 JKNB-A036CBFC F-temp. control knob 1 1 1 1 AC
2- 4 LANG-A059CBPZ Eva holder 47 2 2 2 2 AC
2- 7 FLEGPA083CBKZ Leg holder l ass’y 1 1 1 1 AF
2- 7- 1 FAJS-A015CBKZ Adjustable leg ass’y 2 2 2 2 AE
2- 7- 2 LHLD-A533CBPZ Leg holder l 1 1 1 1 AL
2- 8 FLEGPA084CBKZ Leg holder r ass’y 1 1 1 1 AF
2- 8- 2 LHLD-A534CBPZ Leg holder r 1 1 1 1 AP
2- 13 DHNG-A437CBMZ Upper hinge ass’y 1 1 1 1 AE
2- 14 DHNG-A419CBMZ Bottom hinge r ass’y 1 1 1 1 AD
2- 15 DHNG-A418CBMZ Center hinge r ass’y 1 1 1 1 AE
2- 16 GCOV-A210CBFZ E.v cover 1 1 1 1 AR
2- 17 LCRA-A022CBPZ Fan clamp 1 1 1 1 AC
2- 19 LHLD-A389CBF0 Motor cushion 2 2 2 2 AF
2- 20 NFANPA011CBF0 Propeller fan 100 1 1 1 1 AD
2- 21 PSEL-C067CBEZ E.v cover sealer a 1 1 1 1 AA
2- 22 PSEL-C068CBEZ E.v cover sealer b 1 1 1 1 AA
2- 23 PSEL-C066CBEZ E.v cover sealer c 1 1 1 1 AC
2- 24 PCOVPA308CBFA Terminal cover 1 1 1 1 AE
2- 26 PCOV-A277CBFA R lamp cover 1 1 1 1 AE
2- 27 GCOVPA144CBRA R-c box cover 1 1 1 1
2- 28 HGRL-A210CBRA Fan louver 1 1 1 1 AU
2- 29 GCOV-A228CBFG Upper hinge cover - 1 - 1 AE
2- 29 GCOV-A228CBFH Upper hinge cover 1 - 1 - AE
2- 31 JKNB-A033CBFC R-temp.control knob 1 1 1 1 AC
2- 32 JKNB-A063CBFA V-tray control knob - 1 - 1 AC
2- 38 PGID-A161CBFZ R-air guider - 1 - 1 AG
2- 38 PGID-A168CBFZ R-air guider 1 - 1 - AK
2- 39 PGID-A162CBFZ R-air guider s - 1 - 1 AC
2- 43 LPLTPA323CBMA Panel base 1 - 1 - AN
2- 44 HGRL-A237CBFA F deodo.louver 1 1 1 1 AE
2- 45 HGRL-A238CBFA R deodo.louver 1 1 1 1 AC
2- 46 PFIL-A050CBEZ Deodorizer 2 2 2 2 AM
2- 47 LHLD-A672CBFZ Plasma holder 1 - 1 - AE
2- 49 LSTPPA108CBFA Chilled stopper 2 2 2 2 AC
2- 50 LSTPPA118CBFA Case stopper v 2 2 2 2 AC
2- 55 HGRL-A205CBFA Multi louver l - - 1 1 AM
2- 55 HGRL-A209CBFA Multi louver s 1 1 - - AM
2- 56 PFPFPB334CBFZ R-louver insu.l - - 1 1 AE
2- 56 PFPFPB345CBFZ R-louver insu.s 1 1 - - AE
2- 57 PSEL-C085CBEZ A-sealer r-louver - - 2 2 AC
2- 57 PSEL-C095CBEZ A-sealer r-louver 2 2 - - AB
2- 63 LHLD-A484CBFA Fan motor holder b 1 1 1 1 AH
2- 64 LHLD-A485CBFA Fan motor holder a 1 1 1 1 AH
2- 65 PSEL-B209CBE0 U-sealer handle 2 2 2 2 AB
2- 66 PSHEMA225CBPZ Heater cover 1 1 1 1 AC
2- 67 LPLTMA633CBPZ Drain support al 1 1 1 1 AF
2- 68 PSEL-A415CBE0 E.v cover sealer c 1 1 1 1 AC
2- 69 PSEL-C069CBEZ E.v cover sealer d 1 1 1 1 AA
