18
SJ-D59M/P60M
SJ-D64M/P65M
SJ-D69M/P70M
(2) Fixing of R-fan motor and Fan
(2)-1 Set R-fan motor holder A to R lamp box by
tapping screw.
(2)-2 Set R-fan motor to R fan motor holder A by
machine screw.
(2)-3 Set R fan motor holder B to A.
P
ropeller fan 80
R fan motor holder A
R-fan motor
R fan motor holder
B
Fan clamp
Propeller fan 80
F
Shaft
2.3 0.5mm
+
Fan clamp
Slit
Slit of each Fan clamp and Propeller fa
n
should not be at same position.
Detail of F
Figure A-10
Figure A-9
Lamp 15W
Warning label
Figure A-11
(1) Fixing of Lamp and Lamp socket.
(1)-1 Screw Lamp 15W into Lamp socket.
(1)-2 Fix Lamp socket on R lamp box by tapping
screws.
T
apping screw
Lamp socket
Lamp 15W
R lamp box
ALUMINUM TAP
E
Figure A-7
Figure A-8
Fan motor
L
amp socket
DOUBLE CLAMPING WIRES
(1)-3 Insert the terminal of Lamp socket to R-fan motor.
(2)-4 Set Fan clamp to Propeller fan 80 and insert it
to the shaft of R-fan motor.
(3) Sticking Warning label.
