SMC1585BS
SPECIFICATION
ITEM DESCRIPTION
Power Requirements 120 Volts USA / 117 Volts Canadian
13.0 Amperes (Microwave) / 13.0 Amperes (Convection)
60 Hertz / Single phase, 3 wire grounded
Power Output 900 watts (IEC 705 Test Procedure)
Operating frequency of 2450MHz
Convection Power Output 1450 Watts
Case Dimensions Width 24-5/8" Height 14-7/8" Depth 19-1/8"
Cooking Cavity Dimensions
(1.5 Cubic Feet ) Width 16-1/8" Height 9-5/8" Depth 16-1/8 "
Control Complement Touch Control System
Timer (0 - 99 min. 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI ........................................... Full power throughout the cooking time
P-90 .............................................................. approx. 90% of Full Power
P-80 .............................................................. approx. 80% of Full Power
P-70 .............................................................. approx. 70% of Full Power
P-60 .............................................................. approx. 60% of Full Power
P-50 .............................................................. approx. 50% of Full Power
P-40 ............................................................... approx. 40% of Full Power
P-30 .............................................................. approx. 30% of Full Power
P-20 .............................................................. approx. 20% of Full Power
P-10 ............................................................... approx. 10% of Full Power
P-0 .............................................. No power throughout the cooking time
Convection Temperature for Variable Cooking
CONVECTION ............................................... 100 - 450
ο
F Temp. control
LOW MIX. BAKE ............................... 350
ο
F with 10% microwave power
HIGH MIX. ROAST ............................ 300
ο
F with 30% microwave power
SLOW COOK .......................................... 300
ο
F for 4 hours (no preheat)
BROIL ............................................................................ 450
ο
F (preheat)
Help guide pad, Reheat pad, Easy Minute pad, Popcorn pad
Auto Defrost pad, Sensor Cook pad, Convec Auto Broil pad
Convec Auto Roast pad, Convec Auto Bake pad, Convec pad
Broil pad, Slow Cook pad, Preheat pad, Low mix bake, High mix roast,
Number and temperature selection pads, Kitchen Timer pad, Clock pad
Stop/Clear pad, Power Level pad, Start / Instant On pad
Oven Cavity Light Yes
Sa
fety Standard FCC Authorized, CUL Listed
DHHS Rules, CFR, Title 21, Chapter 1, Subchapter J
Canadian Standards Association.
Health CANADA, Industry CANADA.
GENERAL INFORMATION
GROUNDING INSTRUCTIONS
This oven is equipped with a three prong grounding plug. It must be plugged into a wall receptacle that is properly installed
and grounded.
In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the
electric current.
WARNING: Improper use of the grounding plug can result in a risk of electric shock.

Sharp SMC1585BS Specifications

General

Style	counter top
Color	stainless steel
Total Capacity	1.5 cu. ft.
Control Options	reheat, popcorn, +60 sec, auto broil, auto roast, auto bake, auto defrost, preheat, convect, broil, low & high mix
Convection	yes
Power Levels	10
Sensor Cooking	yes
Quick Start	no
Defrost	by weight or by time
Control Type	touch control
Timer	no
Interior Light	yes
Microwave Power	900 watts
Electrical Requirements	ac 120v/60hz
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	19 inch
Height	14 9/10 inch
Width	24 7/10 inch
Net Weight	60 lbs.
