F E A T U R E S D I A G R A M
OVEN
1. Door handle
2. Oven lamp
3. Door hinges
4. Door safety latches
5. Door
6. Door seals and sealing surfaces
7. Turntable motor shaft
8. Oven cavity
9. Control panel
10. Waveguide cover (DO NOT REMOVE)
11. Power supply cord
12. Ventilation openings
13. Outer cabinet
ACCESSORIES:
Check to make sure the following accessories are
provided:
(14) Turntable (15) Turntable support (16) Coupling
Place the coupling into the turntable motor shaft and then place
the turntable support in the center of the oven floor so that it can
freely rotate around the coupling. Place the turntable onto the
turntable support so that it locates firmly into the coupling. To
avoid turntable damage, ensure dishes and containers are lifted
clear of the turntable rim when removing them from the oven.
NOTE: When you order accessories, please mention two items: part
name and model name to your dealer or SHARP authorized service
agent.
Hub (inside)
14. Turntable
(glass)
16. Coupling
15. Turntable
support
4
1
6
35
7
8
4
2
10
9
11
12
13
8

Sharp SMC1655bS Specifications

General

Style	countertop
Color	stainless steel
Total Capacity	1.6 cubic feet
Sensor Cooking	yes
Timer	yes
Microwave Power	1100 watts
Voltage	120 volts

Weight and Dimensions

Depth	19.3 inches
Height	13 inches
Width	21.8 inches
Net Weight	37.3 pounds
