27
VC-GH61GM/SM,GH611GM
VC-GH60SM,GH600SM,GH601SM
VC-FH310GM/SM
4 Frame R, Frame L, Drive Arm R, Drive Arm L, Upper Plate.
LANGF9661AJFW
Top surface should be free from scratches or soil.
When assemble drive lever to frame R,

make sure the hole synchronize.
Figure 4-44.
