Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
80
VL-H870U
VL-H875U
VL-H890U
VL-H860U
VL-H880U
MISCELLANEOUS PARTS
SC2 QSOCN1986TAZZ Socket, 19Pin AF
SC3 QSOCN1886TAZZ Socket, 18Pin AD
SC6 QSOCN2086TAZZ Socket, 20Pin AD
CN1 QCNCW7089TAZZ Connector, 70Pin AG
DUNTK2892QA00
CAMERA2 UNIT
INTEGRATED CIRCUITS
IC201 RH-iX0470TAZZ IX0470TA, Digital Signal AY
Process
IC251 RH-iX0490TAZZ IX0490TA, Electric Zoom BB
IC252 VHiMS548331-1 MS548331, Field Memory BD
TRANSISTORS
Q201 VSHN2C01FU/-1 HN2C01FU AC
Q202 VSHN2A01FU/-1 HN2A01FU AC
Q203 VS2SC5383F/-1 2SC5383F AB
COILS
L201 VPBWM100KR50N Peaking, 10µHAC
L202 VPCQM470K1R9N Peaking, 47µHAC
L203 VPD9M100J1R7N Peaking, 10µHAC
L205 VPD9M3R9J1R3N Peaking, 3.9µHAC
L207 VPBWM100KR50N Peaking, 10µHAC
L251 VPBWM100KR50N Peaking, 10µHAC
L252 VPBWM100KR50N Peaking, 10µHAC
CAPACITORS
C202 VCCCCZ1HH100D 10p 50V Ceramic AB
C205 VCCCCZ1HH750J 75p 50V Ceramic AB
C206 RC-KZ0051TAZZ Capacitor AC
C207 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C208 VCSATA1AJ106M 10 10V Tantalum AC
C211 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C212 RC-KZ0051TAZZ Capacitor AC
C213 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C214 VCKYCZ1HB222K 2200p 50V Ceramic AB
C215 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C217 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C218 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C219 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C220 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C221 VCKYCZ1HB222K 2200p 50V Ceramic AB
C222 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C223 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C228 RC-KZ0051TAZZ Capacitor AC
C229 VCSATA0JJ156M 15 6.3V Tantalum AC
C230 VCKYCZ1HB102K 1000p 50V Ceramic AB
C231 VCKYCZ1HB102K 1000p 50V Ceramic AB
C251 VCSATA0JJ156M 15 6.3V Tantalum AC
C252 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C253 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C254 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C255 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C256 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C257 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C258 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C259 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C260 VCSATA0JJ156M 15 6.3V Tantalum AC
C261 VCKYCZ1HF103Z 0.01 50V Ceramic AB
RESISTORS
R201 VRS-CZ1JF182J 1.8k 1/16W Metal Oxide AA
R202 VRS-CZ1JF681J 680 1/16W Metal Oxide AA
R205 VRS-CZ1JF273J 27k 1/16W Metal Oxide AA
R206 VRS-CZ1JF123J 12k 1/16W Metal Oxide AA
R207 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R208 VRS-CZ1JF473J 47k 1/16W Metal Oxide AA
R209 VRS-CZ1JF683J 68k 1/16W Metal Oxide AA
R210 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R212 VRS-CZ1JF392J 3.9k 1/16W Metal Oxide AA
R213 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R214 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R216 VRS-CZ1JF822J 8.2k 1/16W Metal Oxide AA
R217 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R218 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R219 VRS-CZ1JF682J 6.8k 1/16W Metal Oxide AA
R220 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R221 VRK-SA1JF224J 220k 1/16W AC
Metal Composition
R222 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R252 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R254 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R256 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB201 RBLN-0120TAZZ Balun, BLN-0120TA AC
FB202 RBLN-0120TAZZ Balun, BLN-0120TA AC
P201 QPLGN0258REZZ Plug, 2Pin AD
SC4 QSOCN1986TAZZ Socket, 19Pin AF
SC5 QSOCN0860TAZZ Socket, 8Pin AE
SC9 QSOCN1860TAZZ Socket, 18Pin AE
CN2 QCNCM7058TAZZ Connector, 70Pin AG
RAMP-0031TAN0
HEAD AMP UNIT
INTEGRATED CIRCUITS
IC301 VHiCXA2032Q-1 CXA2032Q AN
IC302 VHiS24C01A/-1 S24C01A AF
IC1701 VHiLB1950V/-1 LB1950V AQ
IC1702 VHiLB1951V/-1 LB1951V AN
IC1703 VHiLB1638M/-1 LB1638M AK
TRANSISTORS
Q302 VS2SC5384C/-1 2SC5384C AB
Q307 VS2SC5384C/-1 2SC5384C AB
Q315 VSUMG2/////-1 UMG2 AC
Q341 VS2SA1037KQ-1 2SA1037KQ AA
Q342 VS2SA1037KQ-1 2SA1037KQ AA
Q343 VSUPDC144EE-1 UPDC144EE AB
COILS
L303 VPCCM101K2R1N Peaking, 100µHAC
L304 VPCCM220KR45N Peaking, 22µHAC
L305 VPCCM101K2R1N Peaking, 100µHAC
L341 VPD9M100J1R7N Peaking, 10µHAC
L342 VPD9M101J100N Peaking, 100µHAC
L1701 VPCCM2R2MR09N Peaking, 2.2µHAC
L1702 VPCCM2R2MR09N Peaking, 2.2µHAC
CAPACITORS
C301 VCKYCY1CF104Z 0.1 16V Ceramic AA
C302 VCKYCY1HF103Z 0.01 50V Ceramic AA
C303 VCKYCY1HF103Z 0.01 50V Ceramic AA
C304 VCKYCY1HF103Z 0.01 50V Ceramic AA
C305 VCSATA1AJ106M 10 10V Tantalum AC
C306 VCSATA1AJ106M 10 10V Tantalum AC
C309 VCKYCY1HF103Z 0.01 50V Ceramic AA
C310 VCKYCY1HF103Z 0.01 50V Ceramic AA
C311 VCKYCY1HF103Z 0.01 50V Ceramic AA
C313 VCKYCY1HF103Z 0.01 50V Ceramic AA
C314 VCKYCY1HF103Z 0.01 50V Ceramic AA
C315 VCKYCY1HB472K 4700 50V Ceramic AA
C318 VCKYCY1HF103Z 0.01 50V Ceramic AA
C319 VCKYCY1EB103K 0.01 25V Ceramic AA
C320 VCKYCY1EB223K 0.022 25V Ceramic AA
C321 VCSATA1AJ106M 10 10V Tantalum AC
C322 VCKYCY1EB223K 0.022 25V Ceramic AA
C324 VCKYCY1CF104Z 0.1 16V Ceramic AA
C325 VCSATA1AJ106M 10 10V Tantalum AC
C323 VCKYCY1EB103K 0.01 25V Ceramic AA
C326 VCKYCY1HF103Z 0.01 50V Ceramic AA
C340 VCCCCY1HH101J 100p 50V Ceramic AA
C341 VCCCCY1HH151J 150p 50V Ceramic AA
C342 VCCCCY1HH101J 100p 50V Ceramic AA
