Sharp VL-H875U

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
11-15
VL-H870U
VL-H875U
VL-H890U
VL-H870U
VL-H875U
VL-H890U
36 PSPAZ0277TA00 Tilt Spacer AE
37 QPWBH2896TAZZ Tilt FPC AN
38 QSW-Z0324TAZZ Eject/Turn Unit AG
39 RUNTK0344TAZZ Lithium Unit AH
40 PCOVU9034TA00 AV Unit Cover AD
41 LHLDZ1519TAZZ Holder for S.Unit AG
42 QJAKZ0069TAZZ DC Jack AK
43 QJAKZ0070TAZZ Rimocon/Jack Unit AX
44 QSW-Z0322TAZZ VCR Operation Unit AR
45 JKNBP0177TASA Zoom Knob AG
46 LHLDZ1518TAZZ Speaker Holder AG
47 PSPAZ0285TAZZ Zoom FPC Spacer AB
48 QSW-Z0325TAZZ Zoom Power Unit AQ
49 VSP0028P-50WN Speaker AL
50 GCOVA1616TAKA Camera Rear Cover AG
51 QTANZ0141TAZZ B Terminal Unit AN
52 CLNSA0136TA01 Lens BR
53 LHLDZ1499TA00 Lens Holder AD
54 LANGK0468TAFW Touch Angle AE
(VL-H870U/H875U)
54 LANGK0471TAFW Touch Angle (VL-H890U) AD
55 LHLDZ1501TAZZ LCD Holder AG
(VL-H870U/H875U)
55 LHLDZ1502TAZZ LCD Holder (VL-H890U) AG
56 PZETV0343TAZZ LCD Fixing (VL-H870U/H875U) AA
56 PZETV0370TAZZ LCD Fixing (VL-H890U) AB
57 PSPAZ0289TAZZ Touch Panel Sheet AE
(VL-H870U/H875U)
57 PSPAZ0290TAZZ Touch Panel Sheet AF
(VL-H890U)
58 QSW-Z0288TAZZ Touch Panel BN
(VL-H870U/H875U)
58 QSW-Z0303TAZZ Touch Panel (VL-H890U) BM
å 59 CLMPV0043TA01 Lamp Inverter Ass'y AZ
(VL-H870U/H875U)
å 59 CLMPV0044TA01 Lamp Inverter Ass'y
(VL-H890U)
60 CPNLC0047RM01 LCD Panel Ass'y BZ
(VL-H870U/H875U)
60 CPNLC0048RM01 LCD Panel Ass'y (VL-H890U) CD
61 PGiDM0037TAZZ Light Guide Plate AG
(VL-H870U/H875U)
61 PGiDM0030TAZZ Light Guide Plate (VL-H890U) AH
62 PMiR-0021TAZZ Refrection Polarizing Sheet AC
(VL-H870U/H875U)
62 PMiR-0032TAZZ Refrection Polarizing Sheet AD
(VL-H890U)
63 PSHEP0045TAZZ Diffusion Sheet AD
(VL-H870U/H875U)
63 PSHEP0090TAZZ Diffusion Sheet (VL-H890U) AD
64 PSHEP0070TAZZ DBEF (VL-H870U/H875U) AN
64 PSHEP0092TAZZ DBEF (VL-H890U) AN
65 PSHEP0084TAZZ Prism Sheet AG
(VL-H870U/H875U)
65 PSHEP0093TAZZ Prism Sheet (VL-H890U) AH
66 GFTAC1241TASA Cassette Control Cover AD
67 DUNTK2886QA00 VCR Unit (VL-H870U/ —
H870UA/H870UC/H870UW)
67 DUNTK2886QA01 VCR Unit(VL-H875U) —
67 DUNTK2886QA07 VCR Unit(VL-H890U) —
69 DUNTK2892QA00 Camera 2 Unit —
70 DUNTK2889QA00 Camera 1 Unit —
71 PSLDM3336TAFW Camera A Shield AD
72 PSLDM3337TAFW Camera B Shield AD
73 PSHEP0126TAZZ DC Jack Sheet AB
74 PSHEP0127TAZZ AV Terminal Sheet AB
75 PSHEP0128TAZZ Audio Terminal Sheet AB
a LX-HZ0018TAFN M2x6 Tapping Screw, Silver AA
b LX-HZ0018TAFF M2x6 Tapping Screw, Black AA
c LX-HZ0045TAFN M2x4 Tapping Screw, Silver AA
d XiPSF20P04000 M2x4 Small Screw, Black AA
Zinc Plating
e LX-BZ0191TAFD M2 Special Screw AC
f XiPSD20P03000 M2x3 Screw AA
g LX-HZ0045TAFF M2x4 Tapping Screw, Black AA
h LX-HZ0013TAFF M1.7x6 Tapping Screw, Black AA
i XiPSN20P04000 M2x4 Small Screw, Silver AA
j LX-HZ0050TAFN M1.7x4 Tapping Screw, Silver AA
k LX-BZ0236TAFD M2x8 Screw AB
l XiPSF20P03000 M2x3 Screw, Black AA
CASSETTE HOUSING PARTS
400 CHLDX3077GE01 Cassette Compartment AY
Ass'y
401 MSPRT0414GEZZ Up Main Spring AD
402 MROD-0014GEFJ Damper rod AG
403 PDMP-0013GEZZ Cassette Compartment AG
Damper
CAMERA UNIT PARTS
1 PCOVM8019TA00 Dust Protection Rubber AC
2 LANGK0314TAFW Sensor Holder AC
3 PFiLW0062TAZZ Crystal AU
4 VHiLZ2453A6-1 CCD Sensor BK
5 DUNTK2895PM00 CCD Unit —
6 LX-HZ0013TAFF Screw (1.7 X 6) AA
SUPPLIED ACCESSORIES
ACCESSORIES
GCOVH1244TASA Lens Cap AG
å QACCB0016TAZZ AC Cord(VL-H870UW) AV
å QACCK0002TAZZ AC Cord(VL-H870UA) AM
QCNW-1906TAZZ A/V Cable AN
QPLGA0010GEZZ AC Plug(VL-H870UA) AF
RRMCG0074TASA Remote Control AP
TiNSE0319TAZZ Operation Manual AH
(VL-H870U/H870UA/H870UW)
TiNSE0320TAZZ Operation Manual (VL-H875U) AH
TiNSE0321TAZZ Operation Manual AK
(VL-H890U/H890UA/H890UW)
TiNSL0170TAZZ Operation Manual (VL-H870UC)
TiNSL0171TAZZ Operation Manual (VL-H890UC)
UADP-0303TAZZ AC Adapter (VL-H870U/ BC
H870UC/H875U/H890U/H890UC)
UADP-0304TAZZ AC Adapter (VL-H870U/ BC
H870UW/H890UA/H890UW)
UBATi0058TAZZ Battery Pack BF
(VL-H870U/H875U/H890U)
UBATi0059TAZZ Battery Pack
(VL-H870UA/H870UC/H870UW/
H890UA/H890UC/H890UW)
UBATU0243GEZZ Battery
UBATL0011TAZZ Lithium Battery AE
UBNDS0010TASA Shoulder Strap AH
TLABZ0495TAZZ R-C Label(VL-H870UA/
H870UW/H890UA/H890UW)
ACCESSORIES(NOT REPLACEMENT ITEM)
TGANE0044TAZZ Guarantee Card AC
(VL-H870U/H875U/H890U)
TGANZ0021TAZZ Guarantee Card AD
(VL-H870UC/H890UC)
TLABK0001TAZZ No.Card AA
PACKING PARTS
(NOT REPLACEMENT ITEM)
SPAKA6312TAZZ Top Case —
SPAKA6314TAZZ Packing Case —
SPAKA6313TAZZ Bottom Case —
SPAKC7419TAZZ Packing Case(VL-H870U) —
