Sharp VL-H875U User Manual

VL-H870U
VL-H875U
VL-H890U
VL-H870U
VL-H875U
VL-H890U
2-1
2. SPECIFICATIONS
SERVICE INFORMATION (For the U.S.)
For the location of the nearest Sharp Authorized Service, or to obtain product literature, accessories,
supplies or customer assistance, please call 1-800-BE SHARP (1-800-237-4277) or visit SHARP's
website (http://www.sharp-usa.com)
Specifications are subject to change without notice.
Battery Pack BT-L241(VL-H870U/H875U)
DC Output: 7.2V
Dimensions (approx.): 2
1
/
8
" (W) ×
3
/
4
" (H) × 2
7
/
32
" (D)
[54 mm (W) × 19 mm (H) ×
56 mm (D)]
Weight (approx.): 0.30 lbs (136 g)
Battery Pack BT-L241 (VL-H890U)
DC Output: 7.4V
Dimensions (approx.): 1
9
/
16
" (W) × 1
11
/
16
" (H) ×
2
1
/
8
" (D)
[40 mm (W) × 43 mm (H) ×
54 mm (D)]
Weight (approx.): 0.21 lbs (97 g)
AC Adapter UADP-0303TAZZ
(VL-H870U/H870UC/H875U/H890U/H890UC)
AC Adapter UADP-0304TAZZ
(VL-H870UA/H870UW/H890UA/H890UW)
Power Requirement: AC 110-240 V, 50/60 Hz
DC Output: 9.0 V
Power Consumption: 15 W
Dimensions (approx.): 2
11
/
16
" (W) × 1
15
/
32
" (H) × 5
13
/
32
" (D)
[68 mm (W) × 37 mm (H) ×
137 mm (D)]
Weight (approx.): 0.73 lbs (330 g)
Signal System: NTSC standard
Recording System: 2 rotary heads, helical scanning system
Cassette: 8 mm video tape, MP type or Hi8 MP, ME type
Recording/Playback Time: 120 minutes (P6-120)
Tape Speed: 14.345 mm/second
Pickup Device: 1/4" (6.4mm, effective size: 4.5 mm) CCD image sensor (with approx.
410,000 pixels including optical black)
Lens: 22 × power zoom lens (F1.6, f=4.0-88.0 mm) and full-range auto focus
Lens Filter Diameter: 46 mm
Monitor: 3" (7.5 cm) (VL-H870U/H875U)
3.5" (8.8 cm) (VL-H890U)
full-color LCD screen (TFT active matrix)
Microphone: Electret stereo microphone
Color Temperature Compensation: Auto white balance with white balance lock
Minimum Illumination: 4 lux (15 lux measured by EIA standard) (with gain-up, F1.6)
Video Output Level: 1.0 Vp-p 75-ohm unbalanced, S video terminal, Y signal 1.0Vp-p
chroma signal 286mVp-p(Burst)75Ω
Audio Output Level: –8 dBs, impedance less than 2.2 kohms
Speaker Output: 200 mW
External Microphone Input: 3.5 mm diameter mini-plug, –66 dBs, output impedance 6.8kohms, DC
4 V, for plug-in-power microphone use
Power Requirement: DC 7.4V
Power Consumption:
4.9W (VL-H870U/H875U)
5.3W (VL-H890U)
(during camera recording in full auto mode with zoom motor off, Extend
Zoom, DIS and Snapshot functions off, and backlight in normal mode)
Operating Temperature: 0°C to + 40°C (32°F to 104°F)
Operating Humidity: 30% to 80%
Storage Temperature: –20°C to +60°C (–4°F to 140°F)
Dimensions (approx.): 7
3
/
32
" (W) × 4
13
/
32
" (H) × 4
7
/
32
" (D)
[180 mm (W) × 112 mm (H) × 107 mm (D)]
Weight (approx.): 1.66 lbs 755g (VL-H870U/H875U)
1.68 lbs 760g (VL-H890U)
(without battery pack, lithium battery, video cassette, and lens cap)
