STOP REC/PLAY
PLAY STILL
PLAY VSR
VSR PLAY
Capstan motor turns
counterclockwise.
Is take-up reel sensor signal
outputted ?
End
Press REC/PLAY button.
Picture appears at PB.
Unloading
Set capstan motor to search
speed.
End
Press FF button.
PLAY VSF
REC/PLAY STOP
Capstan motor turns in
reverse direction.
Loading motor turns in
counterclockwise direction and
master cam turns clockwise.
Slow brake comes into
contact with capstan motor.
Slow brake
pressing
Cam switch is at STILL
position.
End
Capstan motor stops.
Press STOP button.
Loading motor stops.
End
Capstan motor stops.
NO
YES
Press STILL button.
Pinch
roller
releasing
Idler
swinging
Pinch
roller
pressing
Loading motor turns
clockwise and master
cam turns counterclockwise.
Capstan motor in turns
reverse direction.
Loading motor turns
counterclockwise.
Cam switch is at VSR
position.
Set capstan motor to search
speed.
Is supply reel sensor signal
outputted ?
Press REW button.
Release pinch roller.
Cam switch is at PU2 position.
Cam switch is at PU1 position.
Loading motor stops.
Press pinch roller.
Loading motor turns clockwise.
Release the supply auxiliary
brake.
Loading motor stops.
End
Unloading
Cam switch is at PB position.
End
Press PLAY button.
Loading motor turns counter-
clockwise and master cam
turns clockwise.
Capstan motor turns
counterclockwise. PB speed.
NO
YES
To Next Page
