Sharp WF-930Z(BK)

PRICE
RANK
DESCRIPTIONNO.
PART CODE
★
NO. PARTS CODE
PRICE
RANK
★
DESCRIPTION
WF-930Z
– 1 –
INTEGRATED CIRCUITS
IC1 9FGS3200737872 J AE FM Front End,TA7378P
IC2 9FGS3200180561 J AK IF Amp.& FM MPX.,LA1805
IC101 9FGS3200818972 J AH Pre Amp.,TA8189N
IC251 9FGS3200382257 J AH Graphic Equalizer,BA3822LS
IC401 9FGS3200541557 J AL Power Amp.,BA5415
TRANSISTORS
Q101ç103 9FGS3390140332 J AB Silicon,NPN,9014 C
Q105 9FGS3380500432 J AC Silicon,NPN,8050 D
Q401,402 9FGS3390140332 J AB Silicon,NPN,9014 C
Q501 9FGS3380500432 J AC Silicon,NPN,8050 D
Q502,503 9FGS3390140332 J AB Silicon,NPN,9014 C
Q504 9FGS3385500432 J AC Silicon,PNP,8550 D
DIODES
D1,2 9FGS3600414857 J AA Silicon,1N4148
D4ç6 9FGS3600414857 J AA Silicon,1N4148
D101ç105 9FGS3600414857 J AA Silicon,1N4148
D501 9FGS3600414857 J AA Silicon,1N4148
D502 9FGS3710823557 J AB Zener,8.2V,MTZJ8.2C
D503 9FGS3600414857 J AA Silicon,1N4148
D521,522 9FGS3523200100 J AB LED,Red,L-34HD
îD601ç604 9FGS3600539200 J AB Silicon,1N5392
FILTERS
BPF1 9FGS6319803001 J AE FM Band Pass Filter
CF1 9FGS6321072001 J AC FM IF,10.7 MHz
CF2 9FGS6324550001 J AD AM IF,460 kHz
TRANSFORMERS
L105 9FGS4761000601 J AD Bias Oscillation
T1 9FGS4741000701 J AC FM IF
T2 9FGS4741000701 J AC FM Detection
T3 9FGS4731000511 J AC AM IF
îT601 9FGS4857001232 J AR Power
COILS
L1 9FGS4710040804 J AA FM RF
L2 9FGS4710345803 J AC FM Oscillation
L3 9FGS4608011717 J AB MW/SW1 Bar Antenna
L4 9FGS4691806710 J AB SW1 Antenna
L5 9FGS4720300410 J AC SW2 Antenna
L6 9FGS4721000510 J AC MW Oscillation
L7 9FGS4721000520 J AC SW1 Oscillation
L8 9FGS4721000530 J AC SW2 Oscillation
L101,102 9FGS4522340502 J AC 22 mH,Choke
L103,104 9FGS4527240502 J AC 2.7 mH,Choke
L501 9FGS4522042002 J AC 22 µH,Choke
VARIABLE RESISTORS
VR1 9FGS5392103001 J AC 10 kohm (B),Semi-VR [VCO]
VR251ç254 9FGS5342503002 J AD 50 kohms (B)×2
[Graphic Equalizer]
VR255 9FGS5342503001 J AD 50 kohms (B)×2 [X-BASS]
VR401 9FGS5323503001 J AF 50 kohms (B)×2 [Volume]
VR501 9FGS5392222001 J AC 2.2 kohms (B),Semi-VR
[Tape Speed]
VARIABLE CAPACITORS
FT1 9FGS5451112001 J AH Fine Tuning
TC1,2 9FGS5471112001 J AD Trimmer,10 pF
TC3,4 9FGS5471112002 J AD Trimmer,10 pF
VC5ç8 9FGS5444111001 J AL Variable Capacitor with Trimmer
(TC5ç8)
CAPACITORS
C1 VCCCPU1HH100J J AA 10 pF (CH),50V
C2 VCKYPU1HB102K J AA 0.001 µF,50V
C3 VCCCPU1HH200J J AA 20 pF (CH),50V
C4 VCCCPU1HH5R0C J AA 5 pF (CH),50V
C5 VCKZPU1HF203Z J AA 0.02 µF,50V
C6 VCCRPU1HH270J J AA 27 pF (RH),50V
C7 VCCCPU1HH3R0C J AA 3 pF (CH),50V
C8 VCCCPU1HH150J J AA 15 pF (CH),50V
C9 VCKZPU1HF203Z J AA 0.02 µF,50V
C10,11 VCCCPU1HH5R0C J AA 5 pF (CH),50V
C12 VCCCPU1HH3R0C J AA 3 pF (CH),50V
C13 9FGS4323014120 J 300 pF,50V,Styrol
C14 VCQSMA1HL152J J AB 0.0015 µF,50V,Styrol
C15 VCQSMA1HL472J J AB 0.0047 µF,50V,Styrol
C16 VCCCPU1HH100J J AA 10 pF (CH),50V
C17 RC-GZA106AF1E J AA 10 µF,25V,Electrolytic
C18,19 VCKZPU1HF203Z J AA 0.02 µF,50V
C20 VCQYKU1HM392K J AA 0.0039 µF,50V,Mylar
C21 VCKZPU1HF403Z J AA 0.04 µF,50V
C22 VCKYPU1HB471K J AA 470 pF,50V
C23 VCQYKU1HM822K J AA 0.0082 µF,50V,Mylar
C24,25 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C26 VCQSMA1HL152J J AB 0.0015 µF,50V,Styrol
C27 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C28 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C29 VCKZPU1HF203Z J AA 0.02 µF,50V
C30 VCKZPU1HF403Z J AA 0.04 µF,50V
C31 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C32,33 VCQYKU1HM123K J AA 0.012 µF,50V,Mylar
C34,35 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C36ç38 VCCCPU1HH5R0C J AA 5 pF (CH),50V
C39,40 VCKYPU1HB102K J AA 0.001 µF,50V
C41 VCKZPU1HF203Z J AA 0.02 µF,50V
C42 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C43,44 VCKZPU1HF203Z J AA 0.02 µF,50V
C101ç104 VCKYPU1HB821K J AA 820 pF,50V
C105,106 RC-GZA336AF1A J AB 33 µF,10V,Electrolytic
C107,108 VCQYKU1HM333K J AB 0.033 µF,50V,Mylar
C109ç112 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C113,114 RC-GZA106AF1E J AA 10 µF,25V,Electrolytic
C117,118 VCQYKU1HM153K J AA 0.015 µF,50V,Mylar
C119,120 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C121,122 VCCSPU1HL131J J AB 130 pF,50V
C125,126 VCCSPU1HL151J J AA 150 pF,50V
C127 VCCSPU1HL121J J AA 120 pF,50V
C128 VCCSPU1HL331J J AA 330 pF,50V
C129 VCQYKU1HM102K J AA 0.001 µF,50V,Mylar
C130 VCKZPU1HF203Z J AA 0.02 µF,50V
C131 VCQYKU1HM822K J AA 0.0082 µF,50V,Mylar
C132 VCQYKU1HM123K J AA 0.012 µF,50V,Mylar
C134 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C135,136 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C137 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C138 RC-GZW228AF1A J AE 2200 µF,10V,Electrolytic
C140 RC-GZA106AF1E J AA 10 µF,25V,Electrolytic
C141 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C142 VCQYKU1HM183K J AB 0.018 µF,50V,Mylar
C143 VCKYPU1HB102K J AA 0.001 µF,50V
C144 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C145 9FGS4223221441 J 220 pF,50V
C146 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C147 RC-GZA106AF1E J AA 10 µF,25V,Electrolytic
C148 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C149 RC-GZA106AF1E J AA 10 µF,25V,Electrolytic
C150 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C151,152 VCKYPU1HB331K J AA 330 pF,50V
C153,154 VCKYPU1HB102K J AA 0.001 µF,50V
C155,156 VCKYPU1HB103K J AA 0.01 µF,50V
C251ç256 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C257,258 VCQYKU1HM223K J AB 0.022 µF,50V,Mylar
C259,260 VCQYKU1HM102K J AA 0.001 µF,50V,Mylar
C261,262 VCQYKU1HM333K J AB 0.033 µF,50V,Mylar
C263,264 VCQYKU1HM332K J AA 0.0033 µF,50V,Mylar
C265,266 VCQYKU1HM104K J AB 0.1 µF,50V,Mylar
C267,268 VCQYKU1HM103K J AA 0.01 µF,50V,Mylar
C269,270 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C271,272 VCQYKU1HM333K J AB 0.033 µF,50V,Mylar
C273,274 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C275 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C401,402 VCQYKU1HM102K J AA 0.001 µF,50V,Mylar
C403,404 VCQYKU1HM154K J AC 0.15 µF,50V,Mylar
C405,406 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C407,408 VCKYPU1HB102K J AA 0.001 µF,50V
C409,410 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C411,412 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C413,414 VCQYKU1HM224K J AD 0.22 µF,50V,Mylar
C415,416 RC-GZS108AF1C J AD 1000 µF,16V,Electrolytic
C417 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
!
!
