NO.
PRICE
RANK
DESCRIPTION
PARTS CODE
★
NO. PART CODE
PRICE
RANK
★
DESCRIPTION
WF-930Z
C419 RC-GZW228AF1E J AE 2200 µF,25V,Electrolytic
C420 RC-GZA226AF1E J AB 22 µF,25V,Electrolytic
C502 VCKZPU1HF203Z J AA 0.02 µF,50V
C503 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C504,505 VCKZPU1HF203Z J AA 0.02 µF,50V
C506 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C507 VCKZPU1HF203Z J AA 0.02 µF,50V
C601ç604 VCKZPU1HF203Z J AA 0.02 µF,50V
RESISTORS
R1 VRD-ST2EE101J J AA 100 ohm,1/4W
R2 VRD-ST2EE330J J AA 33 ohms,1/4W
R3 VRD-ST2EE224J J AA 220 kohms,1/4W
R4 VRD-ST2EE470J J AA 47 ohms,1/4W
R5 VRD-ST2EE101J J AA 100 ohm,1/4W
R6,7 VRD-ST2EE470J J AA 47 ohms,1/4W
R8 VRD-ST2EE101J J AA 100 ohm,1/4W
R9 VRD-ST2EE392J J AA 3.9 kohms,1/4W
R10 VRD-ST2EE474J J AA 470 kohms,1/4W
R11 VRD-ST2EE223J J AA 22 kohms,1/4W
R12 VRD-ST2EE104J J AA 100 kohm,1/4W
R13 VRD-ST2EE152J J AA 1.5 kohms,1/4W
R14 VRD-ST2EE102J J AA 1 kohm,1/4W
R15,16 VRD-ST2EE103J J AA 10 kohm,1/4W
R17,18 VRD-ST2EE272J J AA 2.7 kohms,1/4W
R101,102 VRD-ST2EE560J J AA 56 ohms,1/4W
R103,104 VRD-ST2EE184J J AA 180 kohms,1/4W
R105,106 VRD-ST2EE562J J AA 5.6 kohms,1/4W
R107,108 VRD-ST2EE472J J AA 4.7 kohms,1/4W
R109,110 VRD-ST2EE223J J AA 22 kohms,1/4W
R111,112 VRD-ST2EE184J J AA 180 kohms,1/4W
R113,114 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R115,116 VRD-ST2EE221J J AA 220 ohms,1/4W
R117,118 VRD-ST2EE223J J AA 22 kohms,1/4W
R119,120 VRD-ST2EE473J J AA 47 kohms,1/4W
R121,122 VRD-ST2EE223J J AA 22 kohms,1/4W
R123,124 VRD-ST2EE122J J AA 1.2 kohms,1/4W
R125 VRD-ST2EE273J J AA 27 kohms,1/4W
R126 VRD-ST2EE470J J AA 47 ohms,1/4W
R127,128 VRD-ST2EE101J J AA 100 ohm,1/4W
R129ç131 VRD-ST2EE103J J AA 10 kohm,1/4W
R132 VRD-ST2EE221J J AA 220 ohms,1/4W
R133 VRD-ST2EE105J J AA 1 Mohm,1/4W
R134,135 VRD-ST2EE103J J AA 10 kohm,1/4W
R136 VRD-ST2EE472J J AA 4.7 kohms,1/4W
R137 VRD-ST2EE822J J AA 8.2 kohms,1/4W
R138 VRD-ST2EE102J J AA 1 kohm,1/4W
R139 VRD-ST2EE101J J AA 100 ohm,1/4W
R140 VRD-ST2EE102J J AA 1 kohm,1/4W
R141 VRD-ST2EE472J J AA 4.7 kohms,1/4W
R142 VRD-ST2EE334J J AA 330 kohms,1/4W
R143 VRD-ST2EE680J J AA 68 ohms,1/4W
R144 VRD-ST2EE473J J AA 47 kohms,1/4W
R145 VRD-ST2EE472J J AA 4.7 kohms,1/4W
R146,147 VRD-ST2EE103J J AA 10 kohm,1/4W
R148 VRD-ST2EE221J J AA 220 ohms,1/4W
R149 VRD-ST2EE472J J AA 4.7 kohms,1/4W
R150,151 VRD-ST2EE473J J AA 47 kohms,1/4W
R152,153 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R154 VRD-ST2EE101J J AA 100 ohm,1/4W
R155,156 VRD-ST2EE334J J AA 330 kohms,1/4W
R157,158 VRD-ST2EE223J J AA 22 kohms,1/4W
R159 VRD-ST2EE223J J AA 22 kohms,1/4W
R161,162 VRD-ST2EE683J J AA 68 kohms,1/4W
R251,252 VRD-ST2EE102J J AA 1 kohm,1/4W
R253,254 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R257 VRD-ST2EE331J J AA 330 ohms,1/4W
R401,402 VRD-ST2EE272J J AA 2.7 kohms,1/4W
R403ç406 VRD-ST2EE102J J AA 1 kohm,1/4W
R407,408 VRD-ST2EE333J J AA 33 kohms,1/4W
R409,410 VRD-ST2EE121J J AA 120 ohms,1/4W
R413,414 VRD-ST2EE102J J AA 1 kohm,1/4W
R415,416 VRD-ST2EE101J J AA 100 ohm,1/4W
R501 VRD-ST2EE681J J AA 680 ohms,1/4W
R502 VRD-ST2EE101J J AA 100 ohm,1/4W
R503ç505 VRD-ST2EE103J J AA 10 kohm,1/4W
R506 VRD-ST2EE104J J AA 100 kohm,1/4W
R507 VRD-ST2EE682J J AA 6.8 kohms,1/4W
R508 VRD-ST2EE471J J AA 470 ohms,1/4W
R509 VRD-ST2EE563J J AA 56 kohms,1/4W
R510 VRD-ST2EE223J J AA 22 kohms,1/4W
R522 VRD-ST2EE471J J AA 470 ohms,1/4W
OTHER CIRCUITRY PARTS
CNP102 9FGS9425031001 J AB Plug,3Pin
CNP104 9FGS9425041001 J AB Plug,4Pin
CNP201 9FGS9425061001 J AC Plug,6Pin
CNP501 9FGS9425081001 J AC Plug,8Pin
CNP503 9FGS9425021001 J AB Plug,2Pin
CNP505 9FGS9425041001 J AB Plug,4Pin
CNS101 9FGS9395070301 J AD Connector Ass’y,3Pin
CNS103 9FGS9395070401 J AE Connector Ass’y,4Pin
CNS251 9FGS9395070601 J AD Connector Ass’y,6Pin
CNS502 9FGS9395070801 J AE Connector Ass’y,8Pin
CNS504 9FGS9395070201 J AC Connector Ass’y,2Pin
CNS506 9FGS9395070402 J AD Connector Ass’y,4Pin
îF601 9FGS6921123101 J AC Fuse,T1.25A L 250V
J101 9FGS5652355001 J AC Jack,Mixing Microphone
J102 9FGS5653854001 J AD Jack,CD/Line Input
J401 9FGS5640043001 J AE Terminal,Speaker
J403 9FGS5652353401 J AE Jack,Headphones
M501 9FG19900000096 J AQ Motor with Pulley [Tape]
MIC101 9FGS6121101001 J AD Built-in Microphone
îSO601 9FGS5633022101 J AE Socket,AC Power Input
SP701,702 9FGS6111012001 J AM Woofer
SP703,704 9FGS6131152001 J AB Tweeter
SW1 9FGS5118040012 J AD Switch,Slide Type
[Band Selector]
SW101 9FGS5146020011 J AC Switch,Push Type
[Record/Playback]
SW102 9FGS5112030012 J AC Switch,Slide Type [Beat Cancel]
SW103 9FGS5112030022 J AC Switch,Slide Type
[Dubbing Speed/Mic]
SW301 9FGS5142020012 J AD Switch,Push Type [FM Mode]
SW401 9FGS5114030012 J AC Switch,Slide Type
[Function Selector]
SW501 9FG19900000097 J AC Switch,Leaf Type [Tape 2 Main]
SW502 9FG19900000097 J AC Switch,Leaf Type [Tape 1 Main]
SW503 9FG19900000101 J AD Switch,Leaf Type [Tape 2 Play]
îSW601 9FGS5111020012 J AD Switch,Slide Type
[Voltage Selector]
MECHANICAL PARTS
1 9FG001414301 J Base Ass’y
2 9FG192114099 J Lever,Switch Actuator
3 9FG192114089 J Lever,Actuator Push Button
4 9FG020429006 J Lever,Record Button
5 9FG020429038 J Lever,Play Button
6 9FG020429008 J Lever,Rewind Button
7 9FG020429010 J Lever,Fast Forward Button
8 9FG001414026 J Lever,Stop Button
9 9FG020429120 J Pause Button Lever Ass’y
10 9FG001414013 J Spring,Pause Control
11 9FG19211482 J Lever,Pause
12 9FG0204280249 J Spring,Pause Lever
13 9FG020428022 J Stopper,Pause Lever
14 9FG0204280289 J Spring,Button Lever
15 9FG000101501 J Main Chassis Ass’y
16 9FG0014140169 J Spring,Eject Actuator
17 9FG001414017 J Spring,Playback Lever
19 9FG020402318 J Lever,E Kick
21 9FG0014140219 J Spring,Record Button Lever
22 9FG0204280309 J Spring,Button Lever
24 9FG000724080 J Spring,Erase Head Arm
25 9FG000303011 J Plate,Head
26 9FG0014140509 J Spring,Pause Button Lever
27 9FG000724032 J Head Base
28 9FG020428066 J Spring,Button Lever
29 9FG0007240249 J Spring,Head Plate
30 9FG001414018 J Spring,M Control
31 9FG19211434 J Arm,Pause Cam
32 9FG19211437 J Coller,Pause Arm
33 9FG000724040 J Arm,Erase Head
34 9FG0007240569 J Spring,Head Azimuth
35 9FG19900000090 J AC Pinch Roller Arm Ass’y
38 9FG002626004 J Lever,Sensing
39 9FG000707301 J REW/FF Clutch Ass’y
40 9FG19900000098 J AC FF/REW Belt
43 9FG009036304F J Flywheel Ass’y,Tape 2
44 9FG009036301F J Flywheel Ass’y,Tape 1
45 9FG0026260059 J Spring,Gear Plate
– 2 –
!
!
!
