Sharp XL-3000

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-3000/3000C
– 1 –
INTEGRATED CIRCUITS
IC201 VHIKIA4558P-1 J AC Surround Control,KIA4558P
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC401 VHILC75342M-1 J AN Function/Volume Equalizer,
LC75342M
IC601 VHISTK40202-1 J AW Power AMP.,STK40202
IC681 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC701 RH-IX0039SJZZ J System Microcomputer/FL Driver,
IX0039SJ
IC801 VHITA2109F/-1 J AL Servo Pre Amp.,TA2109F
IC802 VHITC9462F/-1 J AZ Servo/Signal Control,TC9462F
IC804 VHIMM1469XH-1 J AN Focus/Tracking/Spin/Sled Driver,
MM1469XH
IC805 VHITA7291S/-1 J AH CD Lid Motor Driver,TA7291S
TRANSISTORS
Q101 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q102 VSKTA1268GR-1 J AC Silicon,PNP,KTA1268 GR
Q103,104 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q201 VS2SK246GR/-1 J AB FET,2SK246 GR
Q203 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q302 VS2SC535-C/-1 J AC Silicon,NPN,2SC535 C
Q306 VS2SC535-C/-1 J AC Silicon,NPN,2SC535 C
Q351 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q601,602 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q603 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q604,605 VS2SD2012Y/-1 J AF Silicon,NPN,2SD2012 Y
Q606 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q607 VS2SD2012Y/-1 J AF Silicon,NPN,2SD2012 Y
Q608 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q609 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q681 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q683 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q702,703 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q706 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q707,708 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q709 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q801 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q802 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q861 VS2SB562-C/-1 J AD Silicon,PNP,2SB562 C
Q901 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q902 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q903 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q904 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q907 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q908 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
DIODES
D201 VHD1N4148//-1 J AA Silicon,1N4148
D301,302 VHD1N4148//-1 J AA Silicon,1N4148
D305 VHD1N4148//-1 J AA Silicon,1N4148
D306 VHD1N4148//-1 J AA Silicon,1N4148
D308 VHD1N4148//-1 J AA Silicon,1N4148
D401~403 VHD1N4004//-1 J AB Silicon,1N4004
D602 VHD1N4148//-1 J AA Silicon,1N4148
D604 VHD1N4148//-1 J AA Silicon,1N4148
1 D651~654 VHD1N5402M/-1 J AE Silicon,1N5402M
1 D657~660 VHD1N4004//-1 J AB Silicon,1N4004
D681~685 VHD1N4004//-1 J AB Silicon,1N4004
D688,689 VHD1N4004//-1 J AB Silicon,1N4004
D720~723 VHD1N4148//-1 J AA Silicon,1N4148
D801 VHPDB5306X+-1 J AR LED,DB5306X
D901,902 VHD1N4004//-1 J AB Silicon,1N4004
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD601 VHEDZ130BSA-1 J AC Zener,13V,DZ13BSA
ZD602 VHEDZ8R2BSC-1 J AB Zener,8.2V,DZ8.2BSC
ZD683,684 VHEMTZJ160C-1 J AB Zener,16V,MTZJ16C
ZD701 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD901 VHEDZ240BSD-1 J AB Zener,24V,DZ24BSD
ZD902 VHEDZ5R6BSB-1 J AC Zener,5.6V,DZ5.6BSB
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF302,303 RFILF0004SJZZ J AG FM RF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0003SJZZ J AF AM IF
TRANSFORMERS
T302 RCILA0007SJZZ J AG AM Tracking
T304 RCILI0005SJZZ J AF FM IF
T306 RCILB0009SJZZ J AG AM Band Coverage
T351 RCILI0004SJZZ J AF AM IF
1 T651 RTRNP0055SJZZ J Power Transformer (Main)
1 T681 RTRNP0056SJZZ J AM Power Transformer (Sub)
COILS
L302 RCILR0003SJZZ J AD FM ANT. [FM RF]
L303 RCILB0010SJZZ J AG FM OSC. [FM Band Coverage]
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L601,602 RCILZ0024AWZZ J AC 3 µH,Choke
L603 VP-DH100K0000 J AB 10 µH,Choke
L702 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L801 VP-DH100K0000 J AB 10 µH,Choke
L802 VP-XHR82K0000 J AC 0.82 µH
L803 VP-DH100K0000 J AB 10 µH,Choke
L806 VP-DH100K0000 J AB 10 µH,Choke
L808 VP-DH2R2K0000 J AB 2.2 µH,Peaking
VARIABLE RESISTOR
VR351 RVR-M0999AFZZ J AB 10 kohm (B),Semi-VR
[FM Mute Level]
VARIABLE CAPACITORS
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCKDV147B/-1 J AH Variable Capacitance,KDV147B
VIBRATORS
X351 RCRM-0007SJZZ J AG VCO,456 kHz
X352 RCRSP0006SJZZ J AF Crystal,4.5 MHz
X701 RCRM-0008SJZZ J AG Ceramic,8 MHz
X702 RCRSP0011AWZZ J AC Crystal,32.768 kHz
X801 RCRSP0002SJZZ J AL Crystal,16.93 MHz
CAPACITORS
C101,102 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C103 RC-EZ0002SJZZ J 10 µF,50V,Electrolytic
C104 VCCSCY1HL3R0C J 3 pF,50V
C105 VCKYPA1HB152K J AA 0.0015 µF,50V
C106 RC-EZ0002SJZZ J 10 µF,50V,Electrolytic
C107 RC-EZ0003SJZZ J 100 µF,50V
C108 VCKYPA1HB152K J AA 0.0015 µF,50V
C109 VCCSCY1HL3R0C J 3 pF,50V
C110 VCKYPA1HB102K J AA 0.001 µF,50V
C111,112 RC-EZ0002SJZZ J 10 µF,50V,Electrolytic
C113 VCKYPA1HF223Z J AB 0.022 µF,50V
C114 RC-EZ0003SJZZ J 100 µF,50V,Electrolytic
C116 VCKYPA1HF223Z J AB 0.022 µF,50V
C120 RC-GZA227AF1C J AB 220 µF,16V,Electrolytic
C125,126 RC-GZW228AF1V J AF 2200 µF,35V,Electrolytic
C201,202 VCKYCY1HB562K J AA 0.0056 µF,50V
C203,204 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C208 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C209 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C211,212 VCKYCY1HB332K J AA 0.0033 µF,50V
C213,214 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C215,216 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C301 VCKYPA1HF123Z J 0.012 µF,50V
C302,303 VCKYCY1HB102K J AA 0.001 µF,50V
C304 VCKYCY1EF103Z J AA 0.01 µF,25V
C305 VCKYCY1HB472K J AA 0.0047 µF,50V
C306 VCCUCY1HJ9R0D J AB 9 pF(UJ),50V
C307 VCKYCY1HB472K J AA 0.0047 µF,50V
C308 VCKYCY1EF223Z J AB 0.022 µF,25V
C309 VCKYCY1HB102K J AA 1000 pF,50V
C310 VCKYCY1EF223Z J AB 0.022 µF,25V
