Sharp XL-3000 - Page 63

XL-3000/3000C
– 8 –
Figure 8 SPEAKER EXPLODED VIEW
A
B
C
D
E
F
G
H
1
23456
SP3 (L-CH)
SP4 (R-CH)
SP1 (L-CH)
SP2 (R-CH)
SP3 (L-CH)
SP4 (R-CH)
Tweeter
Tweeter
Capacitor
909
Capacitor
3.3µF,50V
(N.P)
SP1 (L-CH)
SP2 (R-CH)
SP3,4
SP1,2
Woofer
Woofer
Black
Black
White Line
White Line
909
909
902
908
907
910x2
910x4
906
901
903
905x2
905x2
904
