Sharp XL-3000 Service Manual

XL-3000/3000C
– 8 –
(E2) x7
ø3 x8mm
(E2) x1
ø3 x14mm
(C1) x1
ø3 x6mm
(D1) x1
(E1) x1
Power PWB
Main PWB
(D2) x1
Hook
(C1) x1
ø3 x8mm
Holder PWB
Tuner PWB
Main PWB
(C2) x1
Tuner PWB
(C2) x1
Bottom Cabinet
Figure 8-1
Figure 8-2
(G1) x4
ø2.5 x10mm
(H1) x1
ø3 x8mm
(H2) x1
(H5) x1
(H4) x2
ø2.5 x10mm
(J1) x1
ø2.5 x10mm
(F1) x4
ø2.5 x10mm
Hook
(F2) x4
Display PWB
LED PWB
Switch PWB
Gear Box
CD Mechanism
Bracket
Top Cabinet
Holder PWB
(H3) x1
1 Speaker 1. Net Frame ........... (A1) x1 8-3
2. Front Panel ......... (A2) x1
3. Screw .................. (A3) x6
STEP REMOVAL
PROCEDURE
FIGURE
( A3 ) x2
ø4 x12mm
( A3 ) x4
ø4 x12mm
Tweeter
Woofer
Net Frame
( A1 ) x1
Front Panel
( A2 ) x1
Screwdriver
Figure 8-3
