Sharp XR-11XC User Manual

25
XG-MB50X
XR-11XC
XR-10X/S
XR-20X/S
1 Adjustment of
RGB brightness
1. Select the following group
and subjects.
Group : CONFIRM/AD
Subject : R-BRIGHT
G-BRIGHT
B-BRIGHT
(Process GAMMA interlock)
1. Check the fixed value.
Fixed value : 127
2 Adjustment of
Component
offset
1. Feed 10-step signal with
480P component 100%
amplitude.
2. Select the following group
and subjects.
Group :CONFIRM/AD
Subject : C-R-OS
C-B-OS
(Process GAMMA interlock)
1. Check the fixed value.
C-R-OS : 260
C-B-OS : 260
3 Adjustment of
DLP Brightness
1. Select the following group
and subject.
Group : CONFIRM/DLP
Subject :R-BLK
G-BLK
B-BLK
(Process GAMMA interlock)
1. Check the fixed value.
Fixed value : 256
5 Adjustment of
Video Brightness
1. Feed NTSC 100% wind pat-
tern signal. (Signal with
burst)
2. Select the following group
and subject.
Group : CONFIRM/VIDEO
Subject : V-BRIGHT
1. Check the fixed value.
Fixed value : 68
7 Auto keystone
initialization
(20X only) and
audio output
check
1. Select the following group
and subjects.
Group : ADJUST
CW/Auto KS
Subject : CAL
1. With the set placed on a level surface, press the EN-
TER key and check that K-SENS value is 0 ± 3. Check
that keystone is caused by tilting the unit.
2. Check that the start-up sound is heard from the
speaker when the ENTER key is pressed.
No. Adjusting point Adjusting conditions Adjusting procedure
No. Adjusting point Adjusting conditions Adjusting procedure
4Video Contrast
adjustment
1. Feed NTSC 100% wind
pattern signal. (Signal with
burst)
2. Select the following group
and subjects.
Group : CONIRM/
VIDEO
Subject : V-CONT
1. Check the fixed value.
Fixed value : 124
Check items
