Sharp XR-11XC User Manual

17
XG-MB50X
XR-11XC
XR-10X/S
XR-20X/S
2. Removing the top body
2-1. Remove 8 top body fixing screws to detach the Top body.
REMOVING OF MAJOR PARTS
1. Removing the lamp door and the lamp unit
1-1. Loosen the lamp door fixing screw. Lift off the lamp door.
1-2. Remove 2 lamp unit fixing screws to detach the lamp unit.
Top Body
Bottom Body
2-1
2-1
1-1
1-2
1-2
Lamp Door
Lamp Unit

Sharp XR-11XC Specifications

General

Brand	Sharp
Model	XR-11XC
Category	Projector
Language	English
