1. Calling and quitting the process mode with the control keys on this model.
∗ Although it is possible for the process OUT to exit using the process menu, the IN/OUT toggle command is also
available considering the existing specification.
1-1. Calling and quitting
With the menu not displayed, press the "ENTER", "ENTER", "VOL+", "VOL-", "ENTER", "ENTER" and "MENU"
keys on the remote control (one for C50/45 or P25/20 system is also usable) or on the main unit.
1-2. Others
Press the S2551 process key (toggle) on the main PWB to call and quit the process menu.
Note: When adjusting in the process mode, set a signal with a vertical frequency of 60 Hz or no signal. (May not be
properly adjusted with other signals.)
2. Resetting the lamp timer for this model
2-1. Resetting procedure
In Stand-by, run this command to clear the operating time of the lamp to 0 and turn on the power.
Press and hold """, "ENTER", and "MENU", and then press the "STANDBY/ON" key of the set.
3. Forced disabling of the System-Lock of this model
3-1. Disabling procedure
With System-Lock input window onscreen, press the "MENU", "ENTER", "ENTER", "MENU", "ENTER", "ENTER"
and "MENU" keys, in this order, on the remote controller.
No. Adjusting point Adjusting conditions Adjusting procedure
1. Make the following settings.
Destination Process Remote control
adjustment adjustment
USA SS4 Factory setting at 4
China SS6 Factory setting at 6
Others SS3 Factory setting at 3
17 Delivery set-
tings
1. Connect the unit and a PC
with the RS232C cable.
1. Send a command from the PC, and check it func-
tions correctly.
15 RS232C opera-
tion check
1. Select the following group.
Group :INFO/VERSION.
1. The model name appears in the MODEL field, and
the firmware version in the VERSION field. Check
that they are correct.
16 Model name and
version check
* Writing a software program (before main PWB is mounted)
Use the DLP Composer Lite Ver. 4.2 or higher to download the firmware.
After writing the specified version of firmware to the PWB using the RS232C cable, check the version of the written
firmware.
If no software program is written, all three LEDs light up in the chassis inspection process.
