1. If the stereo system does not have a subwoofer output, check
to see if there is a speaker output terminal in the back.
2. Connect the speaker wire parallel to the speaker output on
the stereo system as shown.
3. Connect the other end of the speaker wire to the universal input
(speaker level input) on the unit as shown. (See Figure 3.)
Operation
1. Once the unit is plugged in and connected to a sound
source, rotate the volume control to the minimum level.
2. Flip the ON/OFF switch ON. The blue LED in front of the
unit illuminates.
3. Turn the sound source’s power on and begin play.
4. When sound is playing at a comfortable level, slowly turn the
volume control up until an acceptable amount of low fre-
quency (bass) is reached.
Caution: If the unit makes distorted sounds and mechanical
noises, turn the volume down.
Installation and Wiring
