Sharper Image SR409 - Page 6

No. Description Qty.
28 Washer (9.5 mm) 2
29 Pedal Cap 2
30 Locking Pin 1
(9.5 mm x 125 mm L)
31 Carriage Bolt 4
(9.5 mm x 63.5 mm L)
32 Acorn Nut 4
(9.5 mm)
33 Bolt 1
(9.5 mm x 82.5 mm L)
34 Nylock Nut 5
(9.5 mm)
35 Screw 2
(3.5 mm x 10 mm L)
36 Bolt 4
(8 mm x 35 mm L)
37 Washer (8 mm) 4
38 Bolt (8 mm x 18 mm L) 4
No. Description Qty.
39 Carriage Bolt 4
(8 mm x 40 mm L)
40 Bolt 4
(12.7 x 143 mm,
9.5 mm threaded)
41 Nylock Nut 4
(8 mm)
42 Bolt 4
(5.5 mm x 20 mm L)
43 Spring Pin 2
44 Hand Pulse Sensor 2
with Wire
45 Hand Pulse Sensor 2
Location
46 Plastic Tube 12
(20 mm x 20 mm)
47 Plastic Tube 2
(16 mm x 58 mm)
Parts List
