Page 3
Mechanical and Environmental
Dimensions: 17” wide x 5.75” high x 14” deep (with feet, no rack ears)
Weight: 17.5 lbs / 8 kg (unboxed)
Rack mountable: Yes, with optional rack ears
Power requirements:
115 VAC or 230 VAC +/- 10% @ 50 / 60 Hz (selectable by rear-panel switch)
Power consumption: <= 25 watts
Fuse:
T1AL 250V for 115 VAC operation
T500mAL 250V for 230 VAC operation
Ventilation and cooling:
While the CD-1 produces little heat, proper location and adequate ventilation should still be provided
to prevent overheating due to heat generated by other components.
17”
14”
5.75”
