Typical Audio Performances| number of channels | 2 |
|---|---|
| frequency response | 20~20, 000 Hz ±0.5 dB |
| signal to noise ratio | 103 dB |
| dynamic range | 100 dB |
| total harmonic distortion | 0.006 % |
| audio output level | 2 V RMS |
| digital output optical wavelength | 660 nm -15 ~ -20 dBm |
Optical Readout System| laser type | Semiconductor AlGaAs |
|---|---|
| wavelength | 760~800 nm |
| numerical aperture | 0.45 |
Signal Format| sampling frequency | 44.1 kHz |
|---|---|
| d/a conversion | Multibit (Sigma-delta conversion) |
| oversampling | 8 times |
General| power supply usa and canada | 120 V ~ 60 Hz |
|---|---|
| power supply europe and australia | 230 V ~ 50 Hz |
| power supply china | 220 V ~ 50 Hz |
| power consumption | 20 W |
| dimension | 440×130×355 mm (17-3/8×5-1/8×14 inches) |
| weight | 8.9 kg (19.6 lbs) |
