SECTION 4 – SXM54, SXM60 MOWER DECK
4-33
SPECIFICATIONS
SXM54 and SXM60 Side Discharge
Mower Decks
SPECIFICATIONS SXM54 SXM60
Tractor Required SX21, SX24 SX21, SX24
Cutting Width (Actual) 1372 mm 1524 mm
Overall Width 1720 mm 1870 mm
Cutting Height (7 positions) 1", 1.5", 2", 2.5", 3", 3.5", 4" 1", 1.5", 2", 2.5", 3", 3.5", 4"
Spindle Speed @ Engine Rated
Speed (3000 rpm)
3060 rpm 2870 rpm
Blade Tip Speed 76.1 m/s 78.5 m/s
Number Of Blades 3 3
Blade Length 475 mm 523 mm
Blade Width 60 mm 60 mm
Blade Thickness 7 mm 7 mm
Shipping Weight 100 kg 120 kg
