Shibaura SX21 - Lubrication and Maintenance Chart

SECTION 3 – LUBRICATION AND MAINTENANCE
3-2
LUBRICATION AND MAINTENANCE CHART
SHIBAURA SX21/SX24 – FRONT-WHEEL DRIVE
NO.
LUBRICATION &
MAINTENANCE ITEMS
CHECK
CLEAN
LUBE
CHANGE
ADJUST
SERVICE
INTERVALS
1
2
3
4
Engine Oil Level
Air Cleaner
Radiator Coolant
Transmission Oil Level
×
×
×
×
Every
10 Hours
or Daily
5
6
1, 7
8
10
26
-
Hydraulic Filter
H.S.T. Filter
Engine Oil & Filter
Tire Pressure
Fuel Filter Element
Wheel Bolt Torque
All Fluid Levels
×
×
×
×
×
×
×
First
50 Hours
8
9
10
12
13
14
16
17
18
19
Tires
Battery
Secondary Fuel Filter
Fan Belt
Front Axle Oil Level
Final Reduction
Gear Cases Oil
Level
Lubrication
Fittings:
3-Point Linkage
Brake Pedal
Pedal Shaft
H.S.T. Pedal Pivot
×
×
D
×
×
×
R A
×
×
×
×
I N
Every
50 Hours
1, 7
2
10
Engine Oil & Filter
Air Cleaner
Element
Secondary Fuel Filter
×
×
× Every
100 Hours
NO.
LUBRICATION &
MAINTENANCE ITEMS
CHECK
CLEAN
LUBE
CHANGE
ADJUST
SERVICE
INTERVALS
20
10
12
21
Brake
Fuel Filter Element
Fan Belt
Wheel Bolt Torque
Steering Free Play
×
×
×
×
×
×
Every
200 Hours
4
5
6
13
14
24
Transmission Oil
Hydraulic Filter
H.S.T. Filter
Front Axle Oil
Final Reduction
Gear Cases Oil
Primary Fuel Filter
×
×
×
×
×
×
Every
300 Hours
22
23
Fuel Injector
Valve Clearance
×
×
×
×
Every
600 Hours
2
3
Air Cleaner
Radiator Coolant
×
×
Seasonal
2 Safety Air Filter Element × Every 3
r
d
Primary
Element
Change or
Every 1000
Hours,
Whichever
Comes First
22
23
②
①⑦⑩
⑰⑱⑲⑳
21
⑧
④
⑯
24
21
⑥
⑬⑭
21
⑨
⑫③
⑧
21
⑤
