SECTION 2 – OPERATION
2-22
WHEEL TREAD SETTINGS
NOTE: Tread settings are measured from center of tire to center of tire.
Front Wheel Settings
Tire Type Tractor Model Setting Note
BAR
18 x 8.50 – 8
Front-Wheel Drive
940 mm
Not Adjustable
Turf
18 x 8.50 - 8
Front-Wheel Drive
940 mm
Not Adjustable
Agricultural
4.00 – 9
Front-Wheel Drive
910 mm
Not Adjustable
IMPORTANT: Never attempt to widen the tread setting by reversing the front wheels on a front-wheel
drive system.
NOTE: Torque front wheel bolts to 88 N·m.
Rear Wheel Settings
Tire Type Tractor Model Setting Note
BAR
26 x 12.00 – 12
Front-Wheel Drive
870 mm
Not adjustable
Turf
26 x 12.00 – 12
Front-Wheel Drive
870 mm
Not Adjustable
Agricultural
7 – 14
Front-Wheel Drive
910 mm
Not Adjustable
Note: Torque rear wheel bolts to 122 N·m.
