SECTION 2 – OPERATION
2-24
CAST IRON WEIGHTS (OPTIONAL)
Cast iron weights are available as accessories
from your SHIBAURA Dealer. Weights can be
mounted on the front end of the tractor and on
the rearmost wheels.
NOTE: Front weight bracket 370220230,
372111070 is required to install front weights.
Front End Weights
Tire Type Weight(s)
Agricultural and Turf Maximum of (2) weights
per tractor @ 30 kg each
60 kg total
