34
Installation/removal
Wiring around the cockpit (clamp band type cycle computer)
` When using cord bands and a cord clip
1. Secure the switch unit's electric wire.
Determine the locations of the cord bands, then secure the electric wire in place along
the handlebar so that there is no slack.
Switch unit
SM-EWE1 (EW-SD50 type)
EW-CB300 (EW-SD300 type)
2. Bind the electric wires and the brake outer casing or brake hose
together with a cord clip.
Use a cord clip to bind the brake outer casing or brake hose and the following electric
wires:
• Switch unit's electric wire
To Next Page
