26
MAINTENANCE
Applying grease
MAINTENANCE
Applying grease
(A)
(B)
(a)
(A)
(C)
(B)
(b)
(A)
(B)
(B)
(A)
Before applying grease for roller
brakes (B), remove the grease hole cap
(A) and press-fit the tube into the back
of the hole 12 mm or more. Apply an
appropriate amount of grease (approx.
5 g) while turning the wheel slowly.
After application, check that braking is
properly applied and that no abnormal
noise is heard.
(a) For BR-C6060-F/C6000/C3000/
C3010
(b) For BR-IM31/35
(A) Grease hole cap
(B) Grease for roller brakes
(C) Cable unit
To Next Page
