DEORE XT Rear Derailleur
RD-M773
(GS)
Long Cage
RD-M773
(SGS)
Super Long Cage
ITEM
NO.
1 Y5XF98010 B-Axle Assembly AA
2 Y5XF98020 Bracket Axle Unit AA
3 Y5XF98030 B-Tension Adjusting Screw (M4 x 18) & Plate A
4 Y5W798030 Cable Fixing Bolt (M5 x 8) & Plate A A
5 Y5W798020 Stroke Adjusting Screws & Plate B A A
6 Y5UC14000 P-Seal Ring AAA
7 Y5W722000 P-Tension Spring AA
Y5W798040 Outer Plate Assembly (GS-Type) A
Y5XF98040 Outer Plate Assembly (SGS-Type) B
9 Y5XF98060 Guide & Tension Pulley Unit B
Y5XF09000 Inner Plate (GS-Type)
Y5XF10000 Inner Plate (SGS-Type)
11 Y53M24400 Pulley Bolt (M5 x13.95) B A
A: Same parts. Mar.-2010-3038
B: Parts are usable, but differ in materirals, appearance, finish, size, etc.
Absence of mark indicates non-interchangeability.
Specifications are subject to change without notice.
8
10
INTERCHANGEABILITY
SHIMANO
CODE NO.
DESCRIPTION
R
D
-
M
9
7
2
R
D
-
M
7
7
2
R
D
-
M
6
6
3
