Shimano SL-U8000 - Page 9

Open the clamp band of the brake lever.
Fixing screw
(1)
(2)
Loosen the fixing screw.(1)
Press the recessed area of the clamp band with a tool such as a 2 mm hexagon wrench to disengage the
safety latch.
(2)
1.
Remove the band adapter on the inner side of the clamp band.
Remove any remaining adhesive.
Band adapter
2.
Installation/removal
Installing the shifter
9
