Installation/removal
Installing the shifter
When installing parts onto a carbon frame/handlebar, confirm the recommended tightening torque with the
carbon frame or handlebar manufacturer. This will prevent damage to the frame/handlebar due to over-torquing
or inadequate securing of the components.
Standard type
I-SPEC II (SL-U8000-IL / SL-U8000-11IR)
For information on brake levers that can be installed, check the compatibility information (
https://productinfo.shimano.com ).
Tighten the fixing screw.
Use a handlebar grip with a maximum outer diameter of Ø36 mm or less.
Fixing screw
(SL-U8000)
3 N·m
(SL-U6000 / SL-U4010 / SL-U4000)
5 N·m
Check that the brake and gear shifting operations are not obstructed.
1.
Installation/removal
Installing the shifter
8
